General
Product Form Factor
Rack-mountable - 1U
Built-in Devices
Led panel
Processor / Chipset
CPU Upgradability
Upgradable
CPU Socket
FCLGA3647 Socket
RAM
Installed Size
0 GB (installed) / 3 TB (max)
Technology
DDR4 SDRAM - Advanced ECC
Slots
24 (Total) / 24 (empty)
Features
Registered, Load-Reduced DIMM (LRDIMM)
RAM Supported
3 TB Load-Reduced - ECC
1.5 TB registered - ECC
192 GB Non-Volatile - ECC
Hard Drive
Storage Controller
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HPE Smart Array S100i SR Software
Optical Storage
Card Reader
Supported Flash Memory Cards
microSD
Monitor
Graphics Controller
Networking
Ethernet Ports
4 x Gigabit Ethernet
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external Universal Media Bay
10 (total) / 10 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 3.0 x16 - three-quarter-length, full-height
1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile
1 (total) / 1 (free) x FlexibleLOM - three-quarter-length, full-height (low-profile)
1 (total) / 1 (free) x microSD Card (internal)
1 (total) / 1 (free) x PCIe x16 - full-height
Interfaces
1 x HPE iLO - Type A (1 in front)
1 x HPE iLO - RJ-45 (1 rear)
5 x USB 3.0 (1 front, 2 rear, 2 internal)
1 x VGA (1 rear)
4 x LAN (Gigabit Ethernet) - RJ-45 (4 rear)
Miscellaneous
Included Accessories
7 x high performance fans
Cables Included
Power cable
Compliant Standards
AES, FIPS 140-2, IPv6 Ready, PCI DSS, TLS v1.2, FIPS 201 PIV, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 120/230 V (50/60 Hz)
Operating System / Software
OS Certified
CentOS, Microsoft Windows Server 2012 R2, VMware vSphere 6.0 (ESXi), SuSE Linux Enterprise Server 11 SP4, Microsoft Windows Server 2016, Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 6.9, VMware vSphere 6.5 (ESXi), SuSE Linux Enterprise Server 12 SP2, ClearOS
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
