General
Device Type
Video conferencing device
Video Codecs
H.264, H.264 High Profile
Quality of Service
IEEE 802.1Q (VLAN), Differentiated Services (DiffServ), IEEE 802.1p
IP Address Assignment
DHCP
Security
256 bit AES, EAP-MD5, IEEE 802.1X, TLS, EAP-TLS, EAP-TTLS, PEAP-MSCHAPv2, PEAP, EAP-MSCHAPv2
Network Protocols
HTTP, HTTPS, Link Layer Discovery Protocol (LLDP), SRTP, SNTP
Built-in Devices
Microphone array, 2 cameras, dual 5 W speakers
Video Input
Type
Digital video camera (colour) - integrated
Features
Microsoft Teams compatible, automatic speaker tracking, auto privacy shutter
Angular Field Of View (max, degree)
120
Video Output
Type
Codec board - integrated
Digital Video Standard
High-Definition Multimedia Interface (HDMI)
Audio Input
Type
8-microphone array - integrated
Audio Output
Output Power / Channel
5 Watt
Networking
Connectivity Technology
Wireless, wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, Bluetooth, Wi-Fi
Network / Transport Protocol
TCP/IP, DHCP, HTTP, HTTPs, IPv4, IPv6
Features
VLAN support, web server, Quality of Service (QoS), reset button, LLDP support, security lock slot (cable lock sold separately), echo cancellation, CHAP support
Compliant Standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x
Expansion / Connectivity
Interfaces
2 x audio / video - HDMI output - 19 pin HDMI Type A ¦ 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 2 x USB 2.0 - 4 pin USB Type A ¦ 1 x accessory - RJ-45 ¦ 1 x audio - line-In - mini-phone 3.5 mm ¦ 1 x audio - line-out - mini-phone 3.5 mm
Miscellaneous
Cables Included
1 x network cable - 3 m ¦ 2 x HDMI cable - 1.8 m
Compliant Standards
ISO 9001, NOM, CCC, FCC, RoHS, ANATEL, REACH, CEC
Power
Power Device
Power adapter - external
Voltage Required
AC 120/230 V
Power Consumption Operational
15 Watt
Software / System Requirements
Software Included
Android 9.0
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 95%
