General
Device Type
UPS - external
Battery Enclosure Type
Internal
Power Device
Input Voltage
AC 208/220 V
Input Voltage Range
AC 165 - 240 V
Frequency Provided
57 - 63 Hz
Frequency Required
40 - 70 Hz
Input Connectors
1 x hardwire 5-wire (3PH + N + G)
Power Output Connectors Details
1 x Terminal Block (Screw)
1 x hardwire 5-wire (3PH + N + G)
Output Voltage
AC 120/208/220 V ± 5% - 57 - 63 Hz
Power Capacity
8 kW / 10000 VA
Circuit Protection
Circuit breaker
Battery
Quantity
2 (installed) / 4 (supported)
Run Time (Up To)
18 min at full load
Networking
Remote Management Interface
Ethernet 10/100, RS-232
Remote Management Protocol
SNMP, Telnet, HTTP, HTTPS
Expansion / Connectivity
Interfaces
1 x management (Ethernet) - RJ-45
1 x EPO (emergency power off)
1 x management (RS-232) - 9 pin D-Sub (DB-9)
Expansion Slots
1 (total) / 0 (free) x SmartSlot
Miscellaneous
Included Accessories
Bolt down brackets
Features
Audible alarm, emergency power off, LCD display, Parallel Capability, built-in maintenance bypass, built-in static bypass
Compliant Standards
FCC Class A certified, ISO 9001, cUL, UL 1778, ISO 14001, FCC Part 15, EN 50091-2, IEC 62040-3, IEC 62040-1-1
Software / System Requirements
Software Included
Drivers & Utilities
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Installation
Technical support - training
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
0 - 95%
Dimensions & Weight
Dimensions & Weight (Shipping)
