Seasonic FOCUS Gold SSR-750FM

Productcode: SSR-750FM | EAN/UPC: 4711173878506

€ 90,04 excl.btw

Seasonic FOCUS Gold SSR-750FM - Power supply (internal) - ATX12V / EPS12V - 80 PLUS Gold - AC 100-240 V - 750 Watt - active PFC

Semi-modular cables
Tight voltage regulation
Cable-free connection design
DC to DC converter design
Multi-GPU setup
Gold plated connectors

Op voorraad: 500 stuk(s)

Levertijd:

Product:
Seasonic FOCUS Gold SSR-750FM

€ 108,95 incl. 21% btw € 90,04excl. 21% btw

Winkelwagen Offerte

Omschrijving

Seasonic FOCUS Gold SSR-750FM - Power supply (internal) - ATX12V / EPS12V - 80 PLUS Gold - AC 100-240 V - 750 Watt - active PFC

Product features

Semi-modular cables
Some cables are permanently attached to the power supply (most of the time the 24-pin and the 8-pin ATX power cables) and the rest of the cables can be used to connect the rest of the available components.
Smart and silent fan control
The intelligent thermal circuit feature is designed to find the optimal balance between the necessity to cool the components and the need to run the power supply in the most silent manner possible.
Fluid Dynamic Fan Bearing
High-performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbency effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan.

Specificaties

General

Device Type

Power supply - active Power Factor Correction (PFC) - internal

Specification Compliance

ATX12V / EPS12V

PSU Form Factor

ATX

Power Device

Input Voltage

AC 100-240 V

Frequency Required

50 - 60 Hz

Power Output Connectors Details

1 x power 24 pin ATX with detachable 4 pin section
1 x power 8 pin EPS12V with detachable 4 pin ATX12V section
4 x 8 pin PCI Express power with detachable 2 pin section
8 x 15 pin Serial ATA power
3 x 4 PIN internal power
1 x 4 PIN mini-power connector

Output Voltage

+3.3, +5, ±12 V

Power Capacity

750 Watt

Output Current

+3.3V - 20 A
+5V - 20 A
+12V - 62 A
-12V - 0.3 A
+5VSB - 3 A

Efficiency

87% at 20% Load, 90% at 50% Load, 87% at 100% Load

Power Factor (PF)

0.99

Modular Cable Management

Yes

80 PLUS Certification

80 PLUS Gold

Miscellaneous

MTBF

100,000 hours

Cooling System

120 mm fan

Features

On/off switch, overheat protection, solid capacitors, gold-plated terminals, over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, DC-DC technology, Smart & Silent Fan Control (S2FC), fluid dynamic bearing cooling fan, semi-modular

Compliant Standards

TUV, BSMI, CB, CCC, RoHS, WEEE, cTUVus, Energy-Related Products (ErP) Lot 6, REACH, EAC

Sustainability Information

ENERGY STAR

Yes

Manufacturer Warranty

Service & Support

Limited warranty - 7 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

50 °C

Dimensions & Weight

Width

15 cm

Depth

14 cm

Height

8.6 cm

This data is supplied by 1WorldSync and matched through an automated process. Truedata is not responsible for errors in this data.
