General
Host Connectivity
Gigabit Ethernet / 2.5 Gigabit Ethernet / 10 Gigabit Ethernet
Enclosure Type
Rack-mountable - 2U
Total Storage Capacity
0 GB
Installed Devices / Modules Qty
0 (installed) / 8 (max)
Built-in Devices
Led panel
Processor / Memory
Processors Installed
1 x Annapurna Labs Alpine AL-324 1.7 GHz
RAM
4 GB (installed) / 16 GB (supported) - DDR4
Flash Memory Installed
512 MB
Storage Controller
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, JBOD
Networking
Data Link Protocol
100Mb LAN, 1GbE, 2.5GbE, 10GbE
Network / Transport Protocol
TCP/IP, IPv4, IPv6, DHCP, DDNS, HTTP, HTTPs, FTP, iSCSI, SMTP, SMB, NFS, PPTP, L2TP, IPSec, SFTP, RTSP
Remote Management Protocol
HTTP, HTTPS, SSH, Telnet, SMTP, SNMP 2, SNMP 3, TFTP, SFTP
Network Services Compatibility
DHCP, DDNS, HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), FTP, Server Message Block (SMB), Microsoft CIFS, Apple File Protocol (AFP), Microsoft Active Directory (AD), Network File System v3 (NFS v3), Network File System v4 (NFS v4), File Level Security (ACLs), FTPS, SFTP
Features
Hardware encryption, Jumbo Frames support, reset button, port trunking, Link Aggregation, load balancing, failover protection, DHCP client, DHCP server, Wi-Fi USB dongle support, Spanning Tree Protocol (STP) support, NAT support, static routing, web server, snapshot (folder and LUN), iSCSI LUN clone/snapshot, VJBOD Cloud, SMS alert, wake on LAN (WOL), LDAP support, myQNAPcloud, Qsync, backup server, file sharing, Access Control List (ACL) support, manageable, firmware upgradable, FTP server, FXP support, Google Drive support, Dropbox support, Microsoft OneDrive support, HiDrive support, Amazon Cloud Drive support, Yandex Disk support, Qfiling, hybrid backup sync, Microsoft Azure support, Amazon S3 support, Amazon Glacier suport, OpenStack Swift-compatible, Alibaba Cloud OSS support, Backblaze B2 support, hubiC support, RTRR server, RTRR client, IPv4 and IPv6 dual stack, Rsync compatible, scheduler, Apple Time Machine compatible, QuMagie, Photo album server, Qsirch, surveillance station, VPN Server, VPN client, OpenVPN client, OpenVPN server, PPTP server, DLNA Media Server, Q'center (NAS CMS), Qfinder Pro, Chromecast support, download client, bandwidth control, Qcontactz, IFTTT agent, Qmiix agent, cloud backup, anti-malware protection, BitTorrent Client, UPnP Media Server, Syslog support, E-mail alert, event log, push notification, Network Access Protection (NAP), ONVIF support
Encryption Algorithm
TLS 1.0, TLS 1.1, TLS 1.2, FIPS 140-2, 256-bit AES, SSL
Security DVR
Expansion / Connectivity
Expansion Bays
8 (total) / 8 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
1 (total) / 1 (free) x PCI Express 2.0 x2
1 (total) / 0 (free) x DIMM 288-pin
Interfaces
2 x 2.5 Gigabit Ethernet - RJ-45
4 x USB 3.2 Gen 1 - Type A
2 x Ethernet 10Gb - SFP+
Miscellaneous
Cables Included
1 x network cable
Features
Dual boot, built-in 2 cooling fans, audible alarm, Online RAID Level Migration (RLM), S.M.A.R.T. support, scheduled power on/off, wake on LAN
Compliant Standards
FIPS 140-2
Included Accessories
24 x flat head screws (for 2.5" HDD), 32 x flat head screws (for 3.5" HDD), power cable
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V
Software / System Requirements
Storage Operating System
QNAP QTS 4.4.3
OS Required
Apple MacOS X 10.10 or later, Ubuntu 14.04, CentOS 7.0, Red Hat Enterprise Linux 6.6, SuSE Linux 12 or later, IBM AIX 7, SunSoft Solaris 10 or higher, Microsoft Windows 7 / 8 / 10, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
