General
Host Connectivity
Gigabit Ethernet
Enclosure Type
Rack-mountable - 1U
Total Storage Capacity
0 GB
Max Supported Capacity
108 TB
Installed Devices / Modules Qty
0 (installed) / 4 (max)
Processor / Memory
Processors Installed
1 x AMD Ryzen Embedded V1500B 2.2 GHz
RAM
2 GB (installed) / 32 GB (supported) - DDR4
Storage Controller
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD
Networking
Data Link Protocol
10Mb LAN, 100Mb LAN, 1GbE
Network / Transport Protocol
FTP, PPTP, L2TP
Remote Management Protocol
Telnet, SSH, SNMP, HTTPS
Network Services Compatibility
Apple File Protocol (AFP), Network File System (NFS), Server Message Block (SMB), Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV)
Features
Wake on LAN (WOL), wake on WAN (WOW), B-tree file system (Btrfs), EXT4 file system, Access Control List (ACL) support, LDAP support, firewall protection, Rsync compatible, Let's Encrypt, iSCSI LUN clone/snapshot, VPN Server, Synology Hybrid RAID, iTunes server, FTP server, PXE support, DNS server, Apple Time Machine compatible, Dropbox support, Link Aggregation, Google Drive support, failover protection, Amazon Cloud Drive support, Yandex Disk support, Microsoft OneDrive support, file station, hubiC support, OpenStack Swift-compatible, Baidu cloud support, Alibaba Cloud OSS support, Backblaze B2 support, MegaDisk support, hardware encryption, antivirus analysis, backup server, file sharing, bandwidth control, surveillance station, load balancing, advanced snapshot technology, file and folder-level data restoration, flexible storage quota system, file self-healing, inline compression
Encryption Algorithm
AES-NI
Security DVR
Expansion / Connectivity
Expansion Bays
4 (total) / 4 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
1 (total) / 1 (free) x PCI Express 3.0 x8
Interfaces
4 x Ethernet 1000Base-T - RJ-45
2 x USB 3.2 Gen 1 - Type A
1 x eSATA
1 x serial (management) - DB-9
Miscellaneous
Features
Scheduled power on/off, built-in 2 cooling fans
Compliant Standards
RoHS, FCC, BSMI, VCCI, RCM, UKCA, EAC, CCC, KC, UL
Included Accessories
Accessory pack
Power
Power Device
Internal power supply
Power Redundancy Scheme
1+1
Voltage Required
AC 100-240 V (50/60 Hz)
Software / System Requirements
Storage Operating System
Synology DiskStation Manager
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 80% RH
