General
Device Type
Hard drive array
Enclosure Type
Rack-mountable - 2U
Chassis
Installed Devices / Modules Qty
0
Supported Devices / Modules Qty
24
Storage
Max Supported Capacity
76.8 TB
Storage Controller
Data Transfer Rate
600 MBps
Cache / Buffer Size (Max)
8 GB
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Storage Controller (2nd)
Hard Drive
Expansion / Connectivity
Expansion Bays
24 (total) / 24 (free) - 2.5" SFF
Interfaces
2 x USB (management) ¦ 2 x Ethernet 1000 (management) - RJ-45
System Requirements
OS Required
HP-UX, Red Hat Linux, SUSE Linux Enterprise Server, Oracle Solaris, Microsoft Windows Server 2012, Citrix XenServer, Oracle Linux, Microsoft Windows Server 2016, VSI OpenVMS, Microsoft Windows Server 2019
Miscellaneous
Compliant Standards
FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 61000-3-2, GS, EN 61000-3-3, CCC, IEC 60950-1, EN 60950-1, FCC Part 15.109, WEEE, RoHS, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A, KN24, KN22 Class A, China RoHS, EN 55022 Class A, EN 55024 Class A, CNS 13438 Class A, UL 6950-1, ICES-003:2004 Class A, AS/NZS CISPR22 Class A
Included Accessories
Rack mounting kit, 2 x 7 m PDU cords
Environmental Standards
Power
Power Device
2 x internal power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 120/230 V - 50/60 Hz
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - parts - 3 years
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
