General
Host Connectivity
Gigabit Ethernet
Total Storage Capacity
0 GB
Installed Devices / Modules Qty
0 (installed) / 4 (max)
Processor / Memory
Processors Installed
1 x AMD Ryzen Embedded R1600 2.6 GHz
RAM
4 GB (installed) / 32 GB (supported) - DDR4
Storage Controller
Interface Type
SATA 6Gb/s / eSATA
RAID Level
RAID 0, RAID 1, JBOD, RAID 5, RAID 6, RAID 10
Networking
Data Link Protocol
10Mb LAN, 100Mb LAN, 1GbE
Network / Transport Protocol
PPTP, OpenVPN, L2TP, DNS, iSCSI, TCP/IP, SFTP, IPSec
Remote Management Protocol
Telnet, SSH, SNMP, HTTP, HTTPS, LDAP, RADIUS
Network Services Compatibility
Server Message Block (SMB), Apple File Protocol (AFP), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1), FTP, Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV), Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), Microsoft Active Directory (AD)
Performance
Sequential read: 625 MB/s
Sequential write: 559 MB/s
Features
Hardware encryption, Link Aggregation, failover protection, B-tree file system (Btrfs), EXT4 file system, wake on LAN (WOL), wake on WAN (WOW), Storage Pool, SSD read-write cache, Synology Hybrid RAID, SSD trim, RAID migration, Windows ACL, NFS Kerberos authentication, High Availability, OpenStack compatible, DLNA Media Server, MailPlus server, surveillance station, VPN Server, Rsync compatible, Let's Encrypt, firewall protection, shared folder encryption, SMB encryption, advanced snapshot technology, file and folder-level data restoration, file self-healing, flexible storage quota system, inline compression, DNS server, RADIUS Server, Alibaba Cloud OSS support, Backblaze B2 support, Baidu cloud support, Dropbox support, Google Cloud Platform support, Google Drive support, hubiC support, MegaDisk support, Microsoft OneDrive support, OpenStack Swift-compatible, Tencent COS support, WebDAV server support, Yandex Disk support, mobile users support, Apple Time Machine compatible
Encryption Algorithm
AES-NI, SSL, TLS
Compliant Standards
DLNA CERTIFIED
Security DVR
Compression Format
H.264, H.265
Image Resolution
1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160
Expansion / Connectivity
Expansion Bays
4 (total) / 4 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
2 (total) / 1 (free) x SO-DIMM 260-pin
2 (total) / 2 (free) x M.2 2280
1 (total) / 1 (free) x PCI Express 3.0 x2
Interfaces
2 x Ethernet 1000Base-T - RJ-45
2 x USB 3.2 Gen 1 - Type A
1 x eSATA
Miscellaneous
Cables Included
2 x network cable
Features
Built-in 2 cooling fans, power recovery, scheduled power on/off, Citrix Ready, security lock slot (cable lock sold separately), reset button
Security Slot Type
Kensington security slot
Compliant Standards
FCC, BSMI, VCCI, RCM, UKCA, EAC, CCC, KC, RoHS
Included Accessories
Accessory pack
Power
Power Device
External power adapter
Voltage Required
AC 100-240 V (50/60 Hz)
Software / System Requirements
Software Included
McAfee AntiVirus (Trial)
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
8 - 80% RH
