General
Host Connectivity
Gigabit Ethernet
Total Storage Capacity
0 GB
Installed Devices / Modules Qty
0 (installed) / 12 (max)
Built-in Devices
Led panel
Processor / Memory
Processors Installed
1 x AMD Ryzen Embedded V1500B 2.2 GHz
RAM
4 GB (installed) / 32 GB (supported) - DDR4
Storage Controller
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD
Networking
Data Link Protocol
10Mb LAN, 100Mb LAN, 1GbE
Network / Transport Protocol
TCP/IP, AppleTalk, LPR/LPD, FTP
Remote Management Protocol
SNMP, Telnet, HTTP, HTTPS, SSH
Network Services Compatibility
Microsoft Active Directory (AD), DDNS, Microsoft CIFS, Network File System (NFS), FTP, Apple File Protocol (AFP)
Features
Firewall protection, E-mail alert, print server, firmware upgradable, MySQL server, web server, backup server, file sharing, Advanced Data Streaming (ADS), SSH support, iTunes server, Samba support, FTP server, SMS alert, BitTorrent Client, e-mail server
Compliant Standards
DLNA CERTIFIED
Expansion / Connectivity
Expansion Bays
12 (total) / 12 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
1 (total) / 1 (free) x PCI Express 3.0 x8
2 (total) / 1 (free) x SO-DIMM 260-pin
Interfaces
2 x USB 3.2 Gen 1 - Type A
4 x Ethernet 1000Base-T - RJ-45
1 x expansion port
Miscellaneous
Features
Built-in 2 cooling fans, lockable, wake on LAN, reset button, scheduled power on/off
Compliant Standards
RoHS, VCCI, BSMI, FCC, KC, EAC, RCM
Included Accessories
Accessory pack
Power
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Operational
73.11 Watt
Software / System Requirements
Storage Operating System
Synology DiskStation Manager
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% RH
