General
Device Type
Hard drive array
Enclosure Type
Rack-mountable - 2U
Chassis
Supported Devices / Modules Qty
24
Storage
HDD Array External Interface
16Gb Fibre Channel
Storage Controller
Data Transfer Rate
1.2 GBps
Cache / Buffer Size (Max)
16 GB
RAID Level
RAID 0, RAID 1, RAID 3, RAID 5, RAID 6, RAID 10
Hard Drive
Expansion / Connectivity
Expansion Bays
24 (total) / 24 (free) x hot-swap - 2.5" SFF
Expansion Slots
2 (total) / 0 (free) x expansion slot
Interfaces
2 x SAS 12Gb/s (output) - 36 pin 4x Mini SAS HD (SFF-8644) ¦ 6 x 16Gb Fibre Channel - SFP+ ¦ 1 x Ethernet 1000 (management) - RJ-45 ¦ 1 x serial (management) - 5 pin Micro-USB Type A ¦ 1 x serial (management) - RJ-45
Miscellaneous
Features
Application snapshots, Dynamic Disk Pool (DDP) Technology
Cables Included
1 x micro-USB to USB cable - 2 m ¦ 2 x power cable (C13-C14) - 1.5 m
Compliant Standards
BSMI CNS 13438 Class A, NOM, EN55024, ICES-003 Class A, UL 60950-1, FCC Part 15 A, GB 17625.1, GB 9254 Class A, CECP, CEL, Directive 2011/65/EU, VCCI Class A, EAC, GB 4943.1, KN32, KN35, CNS 14336-1, EN 55032 Class A, IEC/EN 60950-1, CAN/CSA-C22.2 No. 60950-1, AS/NZS CISPR22 Class A
Included Accessories
Rack mounting kit
Power
Power Device
2 x internal power supply - hot-plug
Voltage Required
AC 120/230 V - 50/60 Hz
80 PLUS Certification
80 PLUS Platinum
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - 3 years - on-site
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
45 °C
Humidity Range Operating
8 - 90% (non-condensing)
