General
Device Type
Hard drive array
Enclosure Type
Rack-mountable - 2U
Localisation
English / Worldwide (excluding China, Japan)
Chassis
Supported Devices / Modules Qty
24
Storage
HDD Array External Interface
8Gb Fibre Channel, iSCSI (1 GbE), iSCSI (10 GbE), 16Gb Fibre Channel
Storage Controller
Cache / Buffer Size (Max)
8 GB
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Storage Controller (2nd)
Hard Drive
Expansion / Connectivity
Expansion Bays
24 (total) / 24 (free) x hot-swap - 2.5" SFF
Interfaces
4 x Ethernet 10Gb (iSCSI) / 16Gb Fibre Channel (output) - SFP/SFP+ ¦ 2 x serial - mini-USB Type B ¦ 2 x management - RJ-45 ¦ 2 x SAS 12Gb/s (input) - 36 pin 4x Mini SAS HD (SFF-8644)
Miscellaneous
Cables Included
1 x USB cable
Compliant Standards
BSMI CNS 13438 Class A, ICES-003, EN55024, CCC, RoHS, EN 60950-1, FCC Part 15 A, GB 17625.1, GB 9254 Class A, VCCI Class A, EAC, NMB-3 Class A, GB 4943.1, RCM, MSIP, NOM-019, UL/CSA60950-1, CNS 14336-1, EN 55032 Class A
Included Accessories
Rack mounting kit
Environmental Standards
Power
Power Device
2 x internal power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 120/230 V - 50/60 Hz
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - 3 years - on-site
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80% (non-condensing)
