General
Device Type
Solid state drive - internal
NAND Flash Memory Type
3D triple-level cell (TLC)
Features
Native Command Queuing (NCQ), shock resistant, TRIM support, Advanced Garbage Collection, Error Correction Code (ECC), thermal sensor, DDR3 DRAM Cache, Advanced Global Wear Leveling, LDPC error correction, Bad Block Management, Power Shield, 3K P/E cycles (Programme/Erase cycles), Dynamic thermal throttling, Read Disturbance, Early Move technology, 112-layer 3D NAND technology, Anti-sulfur technology, Extended Temperature, S.M.A.R.T.
Performance
Drive Writes Per Day (DWPD)
2.16
Drive Transfer Rate
600 MBps (external)
Internal Data Rate
560 MBps (read) / 520 MBps (write)
4KB Random Read
90000 IOPS
4KB Random Write
85000 IOPS
Reliability
Expansion & Connectivity
Interfaces
1 x SATA 6 Gb/s
Power
Power Consumption
5 Watt (operating)
1.3 Watt (sleep)
Software & System Requirements
Software Included
Control Center, Transcend SSD Scope Pro, One Touch Recovery
Miscellaneous
Compliant Standards
BSMI, FCC, UKCA, RoHS 2.0
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
85 °C
Min Storage Temperature
-55 °C
Max Storage Temperature
85 °C
Humidity Range Operating
5 - 95%
Shock Tolerance (non-operating)
1500 g @ 0.5 ms
Vibration Tolerance (operating)
20 g @ 7-2000 Hz
