General
Device Type
Security appliance
Processor / Memory / Storage
Processors Installed
1 x Fortinet FortiASIC SOC4
Networking
Connectivity Technology
Wireless, wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2
Network / Transport Protocol
IPSec
Frequency Band
2.4 GHz, 5 GHz
Performance
VPN throughput (512-bit IPSec): 6.5 Gbps
NGFW throughput: 1 Gbps
SSL inspection throughput: 900 Mbps
IPS throughput: 1.4 Gbps
Firewall throughput: 10 Gbps
Threat protection throughput: 700 Mbps
Firewall throughput (1518-byte UDP): 10 Gbps
Firewall throughput (512-byte UDP): 10 Gbps
Firewall throughput (64-byte UDP): 6 Gbps
Firewall throughput: 9 Mpps
Application control (AVC) throughput: 1.8 Gbps
Capacity
Latency: 4 µs
Concurrent sessions: 700000
New sessions: 35000
Firewall policies: 5000
IPSec VPN tunnels: 200
Virtual domains: 10
Number of FortiSwitches: 16
Number of FortiToken devices: 500
Status Indicators
Link/activity
Features
Firewall protection, antivirus analysis, Intrusion Prevention System (IPS), IPSec Virtual Private Network (VPN), fanless, web threat protection, CAPWAP support, application filtering
Encryption Algorithm
SSL, TLS 1.3
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Expansion / Connectivity
Interfaces
7 x 1000Base-T - RJ-45
2 x FortiLink - RJ-45
3 x 1000Base-T - RJ-45 (WAN / DMZ)
1 x console - RJ-45
1 x USB 3.0 - Type A
Miscellaneous
Compliant Standards
UL, VCCI, C-Tick, cUL, CB, FCC Part 15 Class B
Power
Power Device
External power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
18.7 Watt
Software / System Requirements
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
