General
Product Form Factor
Rack-mountable - 1U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: Europe
Processor / Chipset
CPU
Intel Xeon Silver 4514Y
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology
Cache Memory
Installed Size
L3 Cache - 30 MB
RAM
Installed Size
64 GB (installed) / 8 TB (max)
Effective Memory Speed
2800 MHz
Rated Memory Speed
2800 MHz
Slots
32 (Total) / 30 (empty)
Features
HPE SmartMemory, registered, slots 17 - 32 are available in two-processor configuration only
Configuration Features
2 x 32 GB
Hard Drive
Storage Controller
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
HPE MR408i-o Gen11 SPDM
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
Optical Storage
Monitor
Graphics Controller
Networking
Ethernet Ports
2 x 10 Gigabit Ethernet
Ethernet Controller
Broadcom BCM57416
Data Link Protocol
Gigabit Ethernet, 10 Gigabit Ethernet, Ethernet, Fast Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 6
Features
Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 (full-height)
1 (total) / 0 (free) x PCIe 5.0 x16 (low-profile)
1 (total) / 0 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0
1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (2 processors must be installed)
Interfaces
1 x HPE iLO - Type A (1 in front)
1 x HPE iLO - RJ-45
4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal)
1 x VGA
2 x LAN (1/10 Gigabit Ethernet)
1 x USB 2.0
Miscellaneous
Included Accessories
5 x standard fans
Compliant Standards
ASHRAE Class A3, ASHRAE Class A4, TLS v1.2, AES, FIPS 140-2, IPv6 Ready, PCI DSS, WEEE 2002/95/EC, ACPI 6.4, SMBIOS 3.4, Redfish API, Active Directory v1.0, Triple DES
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-240 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
OS Certified
Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware vSphere 7.0 (ESXi) Update 3, VMware vSphere 8.0 (ESXi) Update 1, VMware vSphere 8.0 (ESXi) Update 2, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 15 SP5 QU1, SUSE Linux Enterprise Micro 5.5, Canonical Ubuntu 20.04.5 LTS, Canonical Ubuntu 22.04 LTS, Oracle Linux 9
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE Server UEFI
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
