General
Product Form Factor
Tower - 4U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: Europe, Middle East, Africa
Processor / Chipset
CPU
Intel Xeon Silver 4510
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Hyper-Threading Technology
CPU Socket
LGA4677 Socket-E
Cache Memory
Installed Size
L3 Cache - 30 MB
RAM
Installed Size
32 GB (installed) / 8 TB (max)
Technology
DDR5 SDRAM - Advanced ECC
Effective Memory Speed
2800 MHz
Rated Memory Speed
2800 MHz
Slots
32 (Total) / 31 (empty)
Features
Registered, slots 17 - 32 are available in two-processor configuration only, HPE SmartMemory, 8-channel memory architecture
Configuration Features
1 x 32 GB
Hard Drive (2nd)
Interface Class
Serial ATA
Storage Controller
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
HPE MR408i-o Gen11 SPDM
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, RAID 60
Optical Storage
Monitor
Graphics Controller
Networking
Interface (Bus) Type
Open Compute Project mezzanine (OCP) 3.0
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5719
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SNMP 3, SMASH CLP
Remote Management Controller
Integrated Lights-Out 6
Features
Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
4 (total) / 4 (free) x PCIe 5.0 x16 (x8 mode)
Interfaces
1 x VGA
1 x serial
4 x LAN (Gigabit Ethernet)
1 x HPE iLO - RJ-45
4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 top)
1 x USB 2.0 (1 bottom)
1 x HPE iLO - Type A (1 in front)
Miscellaneous
Included Accessories
3 standard fans, HPE standard heatsink
Theft/Intrusion Protection
Padlock eye, security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
ACPI 6.1, ASHRAE Class A3, ASHRAE Class A4, FIPS 140-3, SMBIOS 3.1, UEFI 2.7, UEFI Class 3, Redfish API, AES, Triple DES, TLS v1.2, APML, ErP Lot 9
Manufacturer Selling Program
HPE Smart Choice
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-120/200-240 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
Microsoft Windows Server 2025
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
