General
Product Form Factor
Rack-mountable - 1U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: Europe
Processor / Chipset
CPU
Intel Xeon Silver 4510
CPU Upgradability
Upgradable
Cache Memory
Installed Size
L3 Cache - 30 MB
RAM
Installed Size
64 GB (installed) / 2.04 TB (max)
Technology
DDR5 SDRAM - Advanced ECC
Effective Memory Speed
2800 MHz
Rated Memory Speed
2800 MHz
Slots
16 (Total) / 14 (empty)
Features
Registered, HPE SmartMemory, slots 9 - 16 are available in two-processor configuration only
Configuration Features
2 x 32 GB
Hard Drive
Features
Read Intensive, basic carrier, HPE Multi Vendor
Storage Controller
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
HPE MR408i-o Gen11 SPDM
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
Optical Storage
Monitor
Graphics Controller
Networking
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5720
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SNMP 3
Remote Management Controller
Integrated Lights-Out 6
Features
ACPI support, PXE support, Wake on LAN (WoL)
Expansion / Connectivity
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 2 (free) x PCIe 5.0 x16 - full-length, full-height (x16 mode)
1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0
Interfaces
1 x HPE iLO (1 in front) (service port)
3 x USB 3.2 Gen 1 (1 front, 2 rear)
1 x VGA (1 rear)
2 x LAN (Gigabit Ethernet) (2 rear)
Miscellaneous
Included Accessories
7 x standard fans
Compliant Standards
ACPI 6.3, PCIe 5.0, SMBIOS 3.2, Redfish API, AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, DMTF, Active Directory v1.0, PCI DSS, FIPS 140-2, IPv6 Ready, UEFI 2.7
Manufacturer Selling Program
HPE Smart Choice
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 120/230 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
OS Certified
VMware ESX, Windows, Linux
Software
HPE iLO Advanced, HPE OneView Standard (free download), HPE iLO Standard with Intelligent Provisioning
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
