General
Product Form Factor
Rack-mountable - 2U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: Worldwide
Processor / Chipset
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology
Cache Memory
Installed Size
L3 Cache - 60 MB
RAM
Installed Size
64 GB (installed) / 8 TB (max)
Effective Memory Speed
4400 MHz
Rated Memory Speed
4800 MHz
Slots
32 (Total) / 30 (empty)
Features
HPE SmartMemory, registered, slots 17 - 32 are available in two-processor configuration only
Configuration Features
2 x 32 GB
Hard Drive
Storage Controller
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
Intel VROC SATA Software RAID
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
Optical Storage
Monitor
Graphics Controller
Networking
Ethernet Ports
2 x 10/25 Gigabit Ethernet SFP28
Ethernet Controller
Broadcom BCM57414
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 6
Features
Wake on LAN (WoL), PXE support
Compliant Standards
OCP 3.0
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external Universal Media Bay
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 2 (free) x FlexibleLOM
1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height
1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x8 mode)
1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x8 mode)
Interfaces
1 x USB 3.0 (1 in front) (HPE iLO Service Port)
4 x USB 3.0 (2 rear, 2 internal)
1 x HPE iLO - RJ-45 (1 rear)
1 x VGA (1 rear)
2 x LAN (10/25 Gigabit Ethernet) (SFP28) - RJ-45
Miscellaneous
Included Accessories
6 performance fans, HPE Easy Install Rails
Compliant Standards
AES, TLS v1.2, ACPI 6.3, ASHRAE Class A3, ASHRAE Class A4, ErP Lot 9, WEEE 2002/95/EC, FIPS 140-2
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 100/240 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
OS Certified
Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, Canonical Ubuntu, Oracle Linux, Citrix
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
