General
Product Form Factor
Rack-mountable - 2U
Localisation
Region: European Union
Processor / Chipset
CPU
Intel Xeon Silver 4309Y
CPU Upgradability
Upgradable
Cache Memory
RAM
Installed Size
32 GB (installed) / 2 TB (max)
Effective Memory Speed
2933 MHz
Rated Memory Speed
3200 MHz
Slots
32 (Total) / 31 (empty)
Features
Registered, 8-channel memory architecture, HPE SmartMemory, slots 17 - 32 are available in two-processor configuration only
Configuration Features
1 x 32 GB
RAM Supported
8 TB Load-Reduced
2 TB registered
8 TB - HPE Persistent Memory - Optane DC Persistent
Hard Drive
Storage Controller
Storage Controller Name
HPE Smart Array S100i SR Software RAID
Optical Storage
Monitor
Graphics Controller
Networking
Interface (Bus) Type
Open Compute Project mezzanine (OCP) 3.0
Ethernet Ports
2 x 10 Gigabit Ethernet
Ethernet Controller
Broadcom BCM57412
Data Link Protocol
10 Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 5
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 4.0 x16 - full-length, full-height
1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, full-height (x8 mode)
1 (total) / 1 (free) x PCIe 4.0 x16 - full-length, full-height (x8 mode)
Interfaces
1 x HPE iLO - RJ-45
3 x USB 3.0 (1 front, 2 rear)
1 x HPE iLO (service port)
2 x LAN (10Gigabit Ethernet) - SFP+
1 x VGA
Miscellaneous
Included Accessories
4 standard fans, CPU standard heatsink, HPE Easy Install Rails with CMA
Compliant Standards
AES, FIPS 140-2, WEEE, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, UEFI, ACPI 6.3, SMBIOS 3.2
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 120/230 V (50/60 Hz)
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
