General
Product Form Factor
Rack-mountable - 1U
Localisation
Region: Americas, Asia Pacific
Processor / Chipset
CPU Upgradability
Upgradable
Cache Memory
Installed Size
L3 Cache - 12 MB
RAM
Installed Size
16 GB (installed) / 128 GB (max)
Technology
DDR4 SDRAM - ECC
Effective Memory Speed
3200 MHz
Rated Memory Speed
3200 MHz
Slots
4 (Total) / 3 (empty)
Features
Unbuffered, dual channel memory architecture
Configuration Features
1 x 16 GB
Hard Drive
Storage Controller
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HPE Smart Array S100i SR Software RAID
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Monitor
Graphics Controller
Graphics Processor
Matrox G200
Networking
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5720
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external 5.25"
4 (total) / 4 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x16 mode)
1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile (x8 mode)
Interfaces
1 x VGA
2 x LAN (Gigabit Ethernet)
1 x LAN (Gigabit Ethernet) / HP iLO
5 x USB 3.0 (2 front, 2 rear, 1 internal)
Miscellaneous
Included Accessories
3 x system fans, HPE Short Friction Rail kit
Compliant Standards
AES, FIPS 140-2, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, Redfish API, UEFI
Power
Voltage Required
AC 120/230 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Provided
No operating system
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
