General
Product Form Factor
Rack-mountable - 2U
Built-in Devices
Led panel, battery
Front Accessible Bays Qty
1
Localisation
Region: Worldwide
Processor / Chipset
CPU Upgradability
Upgradable
Cache Memory
Installed Size
L3 Cache - 64 MB
RAM
Installed Size
16 GB (installed) / 1 TB (max)
Rated Memory Speed
2933 MHz
Slots
32 (Total) / 31 (empty)
Features
Registered, dual channel memory architecture, HPE SmartMemory, slots 17 - 32 are available in two-processor configuration only
Configuration Features
1 x 16 GB
Hard Drive
Storage Controller
Type
1 x RAID - PCIe 3.0 x8
Controller Interface Type
SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name
HPE Smart Array P408i-a
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Optical Storage
Card Reader
Supported Flash Memory Cards
microSD
Monitor
Graphics Controller
Networking
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HPE 366FLR
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external ¦ 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 3.0 x16 ¦ 2 (total) / 2 (free) x PCIe 3.0 x8
Interfaces
1 x HPE iLO (service port) ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 1 x VGA
Miscellaneous
Included Accessories
HPE Easy Install Rails, 4 standard fans
Compliant Standards
AES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 120/230 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Certified
Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, SuSE Linux Enterprise Server 12 SP3, Red Hat Enterprise Linux 7.4, VMware ESXi 6.5 update 1, VMware ESXi 6.5 update 2, VMware ESXi 6.7
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
