General
Product Form Factor
Rack-mountable - 2U
Localisation
Region: Worldwide (excluding China, Japan)
Processor / Chipset
CPU
Intel Xeon Silver 4210R
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
CPU Socket
FCLGA3647 Socket
Cache Memory
Installed Size
L3 Cache - 13.75 MB
Cache Per Processor
13.75 MB
RAM
Installed Size
32 GB (installed) / 1.5 TB (max)
Technology
DDR4 SDRAM - Advanced ECC
Effective Memory Speed
2400 MHz
Rated Memory Speed
2933 MHz
Slots
24 (Total) / 23 (empty)
Features
Registered, dual rank, slots 13 - 24 are available in two-processor configuration only, HPE SmartMemory
Configuration Features
1 x 32 GB
RAM Supported
3 TB Load-Reduced - ECC
1.5 TB registered - ECC
192 GB Non-Volatile - ECC
6 TB - HPE Persistent Memory - Optane DC Persistent
Hard Drive
Storage Controller
Type
1 x RAID - PCIe 3.0 x8
Controller Interface Type
SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name
HPE Smart Array P408i-a
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Optical Storage
Card Reader
Supported Flash Memory Cards
microSD
Monitor
Graphics Controller
Networking
Ethernet Ports
4 x Gigabit Ethernet
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), ACPI support, PXE support
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x microSD Card (internal)
1 (total) / 1 (free) x PCIe 3.0 x8 - full-length, full-height
1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height
1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height
1 (total) / 0 (free) x FlexibleLOM
Interfaces
1 x HPE iLO - Type A (1 in front)
5 x USB 3.0 (1 front, 2 rear, 2 internal)
1 x HPE iLO - RJ-45
4 x LAN (Gigabit Ethernet) - RJ-45
1 x VGA
Miscellaneous
Included Accessories
Cable management arm, 4 standard fans, SFF Easy install rails
Compliant Standards
AES, TLS v1.2, low halogen, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 120/230 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Certified
CentOS, Microsoft Windows Server 2012 R2, VMware vSphere 6.0 (ESXi), SuSE Linux Enterprise Server 11 SP4, Microsoft Windows Server 2016, Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 6.9, VMware vSphere 6.5, SuSE Linux Enterprise Server 12 SP2, ClearOS
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
