General
Product Form Factor
Ultra micro tower
Processor / Chipset
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Intel Smart Cache
Cache Memory
RAM
Installed Size
16 GB / 32 GB (max)
Technology
DDR4 SDRAM - ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
2666 MHz
Memory Specification Compliance
PC4-21333
Slots
2 (Total) / 1 (empty)
Configuration Features
1 x 16 GB
Hard Drive
Storage Controller
Type
1 x RAID - PCIe 3.0 x4
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HPE Smart Array S100i SR Software RAID
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Monitor
Graphics Controller
Graphics Processor
No graphics
Video Interfaces
VGA, DisplayPort
Networking
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
Intel I350-AM4
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Features
Wake on LAN (WoL), ACPI support, PXE support
Expansion / Connectivity
Bays
4 (total) / 4 (free) x internal 3.5" LFF
Slots
1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile ¦ 1 (total) / 1 (free) x expansion slot (iLO Enablement Kit slot)
Interfaces
1 x VGA ¦ 1 x DisplayPort ¦ 4 x USB 3.2 Gen 1 ¦ 2 x USB 3.2 Gen 2 (2 in front) ¦ 4 x LAN (Gigabit Ethernet)
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
FCC Class B certified, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, AES, FCC CFR47 Part 15, Triple DES, EMC Class B, GB 9254, CNS 13438, TLS v1.2, K24, CISPR 32, EN 55032, K32, ASHRAE Class A2, Redfish API, UEFI
Power
Voltage Required
AC 120/230 V (50/60 Hz)
Operating System / Software
OS Provided
No operating system
OS Certified
Microsoft Windows Server 2016, ClearOS, Red Hat Enterprise Linux 8.0, Microsoft Windows Server 2019, VMware ESXi 6.5 update 3, VMware ESXi 6.7 update 3, Red Hat Enterprise Linux 7.6, Red Hat Enterprise Linux 8.1, Red Hat Enterprise Linux 7.7
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 1 year - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
