General
Recommended Use
Small business, corporate business
Product Form Factor
Rack-mountable - 2U
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
Localisation
Region: Worldwide (excluding China, Japan)
Processor / Chipset
CPU Upgradability
Upgradable
Cache Memory
Installed Size
L3 Cache - 50 MB
RAM
Installed Size
32 GB (installed) / 384 GB (max)
Technology
DDR4 SDRAM - Advanced ECC
Effective Memory Speed
2133 MHz
Slots
24 (Total) / 22 (empty)
Features
Registered, HP SmartMemory
Configuration Features
2 x 16 GB
RAM Supported
PC4-17000 - 384 GB registered
PC4-17000 - 1.5 TB Load-Reduced
Hard Drive
Storage Controller
Type
1 x RAID - PCIe 3.0 x8
Controller Interface Type
SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name
Smart Array P440ar with 2GB FBWC
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Optical Storage
Monitor
Graphics Controller
Graphics Processor
Matrox G200eH2
Networking
Ethernet Ports
2 x 10 Gigabit Ethernet, 4 x Gigabit Ethernet
Ethernet Controller
HP 331i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 0 (free) x CPU
24 (total) / 22 (free) x DIMM 288-pin
2 (total) / 2 (free) x PCIe 3.0 x16 - half-length, full-height (x8 mode)
2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height
1 (total) / 1 (free) x microSD Card (internal)
2 (total) / 2 (free) x PCIe 3.0 x16 - full-length, full-height
Interfaces
4 x LAN (Gigabit Ethernet) - RJ-45
1 x HPE iLO - RJ-45
2 x VGA (1 front, 1 rear)
5 x USB 3.0 (1 front, 2 rear, 2 internal)
2 x LAN (10Gigabit Ethernet)
2 x USB 2.0 (2 in front)
Miscellaneous
Included Accessories
Cable management arm, HP Easy Install Rails
Features
Administrator password, power-on password, serial port I/O control, UEFI BIOS
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, CNS 13438
Power
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 120/230 V
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Citrix XenServer, Canonical Ubuntu
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
