General
Device Type
Switch - Managed
Enclosure Type
Plug-in module
Subtype
10 Gigabit Ethernet
Ports
4 x 1 Gigabit / 10 Gigabit / 8 Gb Fiber Channel / FCoE SFP+ + 1 x 40Gb Ethernet / FCoE QSFP+ (breakout compatible)
Performance
Throughput: 500 Gbps
Capacity
QoS hardware queues: 16
MAC Address Table Size
20000 entries
Jumbo Frame Support
9216 bytes
Remote Management Protocol
RMON
Features
VLAN support, IGMP snooping, firmware upgradable, Data Center Bridging Exchange (DCBX) support, priority-based flow control, Quality of Service (QoS), Deficit Weighted Round Robin (DWRR), Class of Service (CoS)
Compliant Standards
IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1ab (LLDP), IEEE 802.1Qaz
Expansion / Connectivity
Interfaces
4 x SFP+ ¦ 1 x QSFP+ ¦ 1 x 1000Base-T RJ-45 management ¦ 1 x console RJ-45 ¦ 1 x USB Type A
Miscellaneous
Compliant Standards
CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, VCCI Class A, KN22 Class A, EN 55022 Class A, CAN/CSA-C22.2 No. 60950-1
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
35 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 95% (non-condensing)
