General
Type
Document scanner - desktop
Interface Type
Gigabit LAN, USB 3.1 Gen 1
Max Supported Document Size
216 x 355.6 mm
Scanner
Grayscale Depth (External)
8-bit (256 grey levels)
Colour Depth (External)
24-bit (16.7 million colours)
Optical Resolution
600 dpi x 600 dpi
Interpolated Resolution
1200 dpi x 1200 dpi
Scanning Sensor Type
Dual CCD
Bulb / Light Source Type
White LED array
Max Document Scan Speed B/W
60 ppm
Max Document Scan Speed Colour
60 ppm
Duty Cycle
4000 scans per day
Scanner Speed Details
60 ppm - portrait - A4 - 200 dpi
60 ppm - portrait - A4 - 300 dpi
120 ipm - duplex - colour - 200 dpi
120 ipm - duplex - colour - 300 dpi
120 ipm - duplex - greyscale - 200 dpi
120 ipm - duplex - greyscale - 300 dpi
120 ipm - duplex - black & white - 200 dpi
120 ipm - duplex - black & white - 300 dpi
Scanner Features
Built-in LCD screen, Ultrasonic sensor, Intelligent Sonic Paper Protection (iSOP), 4.3" touch screen TFT display, NFC authentication
Compliant Standards
TWAIN, ISIS
Media Handling
Max Document Size
216 mm x 5588 mm
Supported Document Type
Plain paper, plastic card
Document Feeder Type
Automatic
Document Storage Capacity
80 sheets
Expansion / Connectivity
Interfaces Details
USB 3.1 Gen 1
Gigabit LAN
Miscellaneous
Included Accessories
ADF paper chute
Cables Included
1 x USB cable
Environmental Standards
Power
Power Device
External power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational (Standby)
42 Watt
Power Consumption Stand by
0.35 Watt
Power Consumption Sleep
2.4 Watt
Software / System Requirements
Software Included
ScanSnap Manager, ABBYY FineReader for ScanSnap, Scanner Central Admin, Software Operation Panel, PaperStream IP, PaperStream Capture
OS Required
Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows 7 (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2012 x64 Edition, Windows 8.1 (32/64 bits), Microsoft Windows Server 2012 R2 x64 Edition, Windows 10 (32/64 bits), Microsoft Windows Server 2016 (64-bit)
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80% (non-condensing)
