General
Type
Barcode scanner - handheld
Barcode
Scan Element Type
Visible laser diode
Light Source Wave Length
650 nm
Max Working Distance
76 cm
Print Contrast Signal (PCS)
20%
Decode Capability
Code 93, Code 39, UCC/EAN-128, IATA, GS1 DataBar, Code 39 Full ASCII, Discrete 2 of 5, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, MSI-Plessey, Code 128 Full ASCII, Code 39 Trioptic
Connectivity Technology
Wired
OK Notification
Beeper, LED indicator
Features
Triggered, Advanced Data Formatting (ADF)
Expansion / Connectivity
Interfaces
1 x RS-232 - DB-9
Miscellaneous
Included Accessories
Stand
Cables Included
1 x serial cable - external
Compliant Standards
Plug and Play, VCCI, EN 60950, IEC950, UL 1950, ICES-003 Class B, FCC Part 15 B, MITI, EMC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 950, IEC 60825-1, CSA C22.2 No. 60950-1, EN 60825-1
Power
Power Device
Power adapter
Electric Current Required
130 mA (typical), 175 mA (peak)
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
5 - 95% (non-condensing)
Drop Specification
1.5 m to concrete
