Processor
Processorfamilie
Intel® Core™ i3
Processor socket
BGA 1744
Processormodel
i3-13300HRE
Basisfrequentie processor
2,1 GHz
Processorgeneratie
Intel Core i3-13xxx
Processor aantal threads
12
Maximale turbofrequentie van processor
4,6 GHz
Prestatie-kernboostfrequentie
4,6 GHz
Efficiënte kernboostfrequentie
3,4 GHz
Processor cache type
Smart Cache
Thermal Design Power (TDP)
45 W
Processor basisvermogen
45 W
Maximaal turbovermogen
115 W
Maximaal gegarandeerd vermogen
65 W
Minimum gegarandeerd vermogen
35 W
Minimum gegarandeerde frequentie
1,2 GHz
Maximaal gegarandeerd vermogen
2,6 GHz
Codenaam processor
Raptor Lake
Geheugen
Geheugen kanaal
Dubbelkanaals
Maximaal intern geheugen ondersteund door processor
96 GB
Geheugentypen ondersteund door processor
LPDDR5x-SDRAM, DDR4-SDRAM, DDR5-SDRAM, LPDDR4x-SDRAM, LPDDR5-SDRAM
Klokgeheugen-snelheden ondersteund door processor
3200,4267,5200,6400 MHz
Grafisch
Ingebouwde grafische adapter
Ja
Aparte grafische adapter
Nee
On-board graphics adapter model
Intel® UHD Graphics
Discreet grafische adapter model
Niet beschikbaar
On-board ondersteunde grafische adapter uitgangen
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
Graphics on-board -adapter dynamische frequentie (max)
1300 MHz
Aantal displays ondersteund (door on-board grafische adapter)
4
On-board grafische adapter DirectX-versie
12.1
On-board grafische adapter OpenGL versie
4.6
Graphics aan boord maximale resolutie adapter (DisplayPort )
7680 x 4320 Pixels
Maximale resolutie (eDP - Integrated Flat Panel)
4096 x 2304 Pixels
Maximale resolutie ingebouwde grafische adapter (HDMI)
4096 x 2304 Pixels
Grafische adapter refresh rate on-board bij maximale resolutie (DisplayPort )
60 Hz
Refresh rate op maximale resolutie (eDP - Integrated Flat Panel)
120 Hz
Verversingsfrequentie ingebouwde grafische adapter bij maximale resolutie (HDMI)
60 Hz
On-board grafische adapter ID
0xA7A8
Aantal verwerkingseenheden
48
Multi-Formaat Codec-motoren
1
Kenmerken
Thermal Monitoring Technologies
Ja
Gebruiksvoorwaarden
Industrial Extended Temp
Maximaal aantal PCI Express-lijnen
28
PCI Express slots versie
5.0
Ondersteunde instructie sets
AVX 2.0, SSE4.1, SSE4.2
Functionele veiligheid (FuSa) documentatie beschikbaar
Ja
Ingebouwde opties beschikbaar
Ja
Processor speciale functies
Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Quick Sync Video Technology
Ja
Intel® Flex Memory Access
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Intel® Speed Shift-technologie
Ja
Intel® Time Coordinated Computing (Intel® TCC)
Ja
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Ja
Intel® Image Processing Unit
6.0
Intel® Control-flow Enforcement Technology (CET)
Ja
Intel® Thread Director
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® High Definition Audio (Intel® HD Audio)
Ja
Intel® Smart Sound Technology
Ja
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Ja
Intel® Volume Management Device (VMD)
Ja
Mode-based Execute Control (MBE)
Ja
Chipset / PCH PCIe Revisie
Gen 3
Microprocessor PCIe Revision
Gen 5
Intel®-technologie voor dreigingsdetectie (TDT)
Ja
Eisen aan de omgeving
Maximale temperatuur (in bedrijf)
100 °C
Gewicht en omvang
Verpakkingsgrootte processor
50 x 25 mm
Overige specificaties
Maximum intern geheugen
96 GB
Grafische uitvoer
eDP 1.4b, DP 1.4a, HDMI 2.1
