Intel Core Ultra 7 270K Plus. Processorfamilie: Intel Core Ultra 7, Processor socket: FCLGA1851, Type verpakking: Doos. Neurale verwerkingseenheid (NPU): Intel AI Boost, AI-softwareframeworks ondersteund door NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN, Totale processorprestaties tot: 36 TOPs. Geheugen kanaal: Dubbelkanaals, Maximaal intern geheugen ondersteund door processor: 256 GB. On-board graphics adapter model: Intel Graphics, Basisfrequentie ingebouwde grafische adapter: 300 MHz, Graphics on-board -adapter dynamische frequentie (max): 2000 MHz. Marktsegment: Desktop, Gebruiksvoorwaarden: Workstation, PC/Client/Tablet, PCI Express slots versie: 4.0, 5.0
Processor
Processorfamilie
Intel Core Ultra 7
Aantal processorkernen
24
Processor socket
FCLGA1851
Processor operating modes
64-bit
Processorgeneratie
Intel Core Ultra (Series 2)
Processor aantal threads
24
Cores met laag energieverbruik
0
Maximale turbofrequentie van processor
5,5 GHz
Prestatie-kernboostfrequentie
5,4 GHz
Prestatie-kernbasisfrequentie
3,7 GHz
Efficiënte kernboostfrequentie
4,7 GHz
Efficiënte kernbasisfrequentie
3,2 GHz
Processor cache type
Smart Cache
Processor basisvermogen
125 W
Maximaal turbovermogen
250 W
AI-softwareframeworks ondersteund door CPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Maximum aantal DMI lanes
8
Codenaam processor
Arrow Lake
Neurale verwerkingseenheid (NPU)
Neurale verwerkingseenheid (NPU)
Intel AI Boost
Sparsity-ondersteuning
Ja
Ondersteuning voor Windows Studio-effecten
Ja
AI-softwareframeworks ondersteund door NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Totale processorprestaties tot
36 TOPs
NPU-prestaties tot
13 TOPs
GPU-prestaties tot
8 TOPs
Geheugen
Geheugen kanaal
Dubbelkanaals
Maximaal intern geheugen ondersteund door processor
256 GB
Grafisch
Ingebouwde grafische adapter
Ja
Aparte grafische adapter
Nee
On-board graphics adapter model
Intel Graphics
Discreet grafische adapter model
Niet beschikbaar
Basisfrequentie ingebouwde grafische adapter
300 MHz
Graphics on-board -adapter dynamische frequentie (max)
2000 MHz
Aantal displays ondersteund (door on-board grafische adapter)
4
On-board grafische adapter DirectX-versie
12.0
On-board grafische adapter OpenGL versie
4.5
Graphics aan boord maximale resolutie adapter (DisplayPort )
7680 x 4320 Pixels
Grafische adapter refresh rate on-board bij maximale resolutie (DisplayPort )
60 Hz
Refresh rate op maximale resolutie (eDP - Integrated Flat Panel)
120 Hz
Verversingsfrequentie ingebouwde grafische adapter bij maximale resolutie (HDMI)
60 Hz
On-board grafische adapter ID
0x7D67
Hardware coderen/decoderen codecs ondersteund
H.264, H.265 (HEVC)
AI-softwareframeworks ondersteund door GPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebGPU
Kenmerken
Thermal Monitoring Technologies
Ja
Gebruiksvoorwaarden
Workstation, PC/Client/Tablet
Maximaal aantal PCI Express-lijnen
24
PCI Express slots versie
4.0, 5.0
Ondersteunde instructie sets
AVX 2.0, SSE4.1, SSE4.2
Ingebouwde opties beschikbaar
Nee
Thermal solution specificatie
PCG 2020A
Directe media-interface (DMI) revisie
4.0
Processor speciale functies
Intel® Hyper Threading Technology (Intel® HT Technology)
Nee
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Enhanced Intel SpeedStep Technology
Ja
Intel® Trusted Execution Technology
Ja
Intel® Speed Shift-technologie
Ja
Intel® Turbo Boost Max Technology 3.0 frequency
5,5 GHz
Intel® Control-flow Enforcement Technology (CET)
Ja
Intel® Thread Director
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® Active Management Technology (Intel® AMT)
Ja
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Intel® Turbo Boost Max Technology 3.0
Ja
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Ja
Intel® Volume Management Device (VMD)
Ja
Mode-based Execute Control (MBE)
Ja
Intel® vPro™ Platform Eligibility
Ja
Intel® Standard Manageability (ISM, Standaard beheerbaarheid)
Ja
Intel® One-Click Recovery (Herstel met 1 klik)
Ja
Intel® Stabiel IT-platformprogramma (SIPP)
Ja
Intel® Remote Platform Erase (RPE)
Ja
Intel® virtualisatietechnologie met omleidingsbescherming (VT-rp)
Ja
Intel® Deep Learning Boost (Intel® DL Boost) on GPU
Ja
Intel vPro® Enterprise-platformvoorwaarden
Ja
Intel®-technologie voor dreigingsdetectie (TDT)
Ja
Intel® totale geheugencodering - Meerdere sleutels
Ja
Intel vPro® Essentials-platformvoorwaarden
Ja
Eisen aan de omgeving
Maximale temperatuur (in bedrijf)
105 °C
Gewicht en omvang
Verpakkingsgrootte processor
45 x 37.5 mm
Overige specificaties
Maximum intern geheugen
256 GB
Grafische uitvoer
eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
