General
Printer Type
Label printer - direct thermal - monochrome
Localisation
United Kingdom, Europe
Printer
Print Speed
Up to 152 mm/sec - max speed
Connectivity Technology
Wireless
Interface
USB 2.0, LAN, serial, USB host, Wi-Fi(ac), Bluetooth 4.1
Max Resolution (B&W)
300 dpi
Language Simulation
ZPL II, EPL2, ZBI, Extensible Mark-up Language (XML), PDF Direct
Features
Realtime clock, Print Touch tag, transmissive/gap sensor, reflective/black mark sensor
Fonts Included
16 x bitmapped ZPL II ¦ 2 x scalable ZPL ¦ 5 x expandable EPL2
Barcodes
Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, ISBT 128, QR code, MaxiCode, Aztec code, LOGMARS, UPC-A, UPC-E, MicroPDF417, Codabar, Code 128, Code 11, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, PLANET, Plessey, Standard 2 of 5, EAN-8, EAN-13, MSI
RAM
RAM Installed (Max)
256 MB
Technology / Form Factor
SDRAM
Flash Memory
Media Handling
Media Type
Receipt paper, tag stock, continuous labels, die cut labels, wristband labels, fanfold labels
Max Media Size
Roll (10.8cm)
Min Media Size (Custom)
15 mm
Max Media Size (Custom)
108 mm x 991 mm
Media Sizes
Roll (1.5 - 10.8 cm)
Media Thickness Range
0.08 mm - 0.19 mm
Roll Maximum Outer Diameter
127 mm
Roll Core Diameter
25.4 mm, 76.2 mm, 38.1 mm, 12.7 mm, 50.8 mm
Media Feeders
1 x manual - 1 roll - Roll (10.8cm)
Networking
Expansion / Connectivity
Connections
1 x USB 2.0 - 4 pin USB Type B ¦ 1 x USB host - 4 pin USB Type A ¦ 1 x LAN - RJ-45 ¦ 1 x RS-232 - 9 pin D-Sub (DB-9)
Miscellaneous
Included Accessories
2 core adapters, 2 ribbon cores
Cables Included
1 x USB cable
Features
Printer setup mobile app via BLE connection
Compliant Standards
FCC Class B certified, VCCI, C-Tick, BSMI, EN 61000-3-2, ICES-003, NOM, SABS, EN 61000-3-3, EN55024, EN55022 Class B, FCC Part 15.247, CCC, IC, IEC 60950-1, KCC, FCC Part 15.209, S Mark, cTUVus, EN 62311, EN 300 328, BIS, INMETRO, CU, RSS-247, IEC 62368-1, EN 301 893, RoHS 2011/65/EU Amendment 2015/863
Power
Power Device
Power adapter - external
Voltage Required
AC 120/230 V
Frequency Required
50/60 Hz
Power Factor Correction
Yes
Environmental Standards
Manufacturer Warranty
Service & Support
Limited warranty - 2 years
Environmental Parameters
Min Operating Temperature
4.4 °C
Max Operating Temperature
41 °C
Humidity Range Operating
10 - 90% (non-condensing)
Dimensions & Weight
