General
Printer Type
Label printer - thermal transfer - monochrome
Localisation
United Kingdom, Europe
Printer
Print Speed
Up to 203 mm/sec - B/W - 203 dpi
Connectivity Technology
Wireless
Interface
USB 2.0, LAN, serial, USB host, Bluetooth LE
Max Resolution (B&W)
203 dpi
Language Simulation
ZPL II, EPL2, ZBI, Extensible Mark-up Language (XML)
Features
Realtime clock, Black Mark sensor, gap sensor, cutter
Fonts Included
16 x bitmapped ZPL II
2 x scalable ZPL
5 x expandable EPL2
Barcodes
Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, ISBT 128, QR code, MaxiCode, Aztec code, LOGMARS, UPC-A, UPC-E, MicroPDF417, Codabar, Code 128, Code 11, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, PLANET, Plessey, Standard 2 of 5, EAN-8, EAN-13, MSI
RAM
RAM Installed (Max)
256 MB
Technology / Form Factor
SDRAM
Flash Memory
Media Handling
Media Type
Receipt paper, tag stock, continuous labels, die cut labels, wristband labels, fanfold labels
Max Media Size
Roll (11.8 cm)
Media Sizes
Roll (11.8 cm)
Max Printing Length
991 mm
Media Thickness Range
0.08 mm - 0.19 mm
Roll Maximum Outer Diameter
127 mm
Roll Core Diameter
25.4 mm, 76.2 mm, 38.1 mm, 12.7 mm, 50.8 mm
Media Feeders
1 x manual - 1 roll - Roll (11.8 cm)
Networking
Expansion / Connectivity
Connections
1 x USB 2.0 - 4 pin USB Type B
1 x USB host - 4 pin USB Type A
1 x LAN - RJ-45
1 x RS-232 - 9 pin D-Sub (DB-9)
Miscellaneous
Compliant Standards
FCC Class B certified, VCCI, C-Tick, BSMI, EN 61000-3-2, ICES-003, NOM, SABS, EN 61000-3-3, EN55024, EN55022 Class B, FCC Part 15.247, CCC, IC, IEC 60950-1, KCC, FCC Part 15.209, S Mark, cTUVus, EN 62311, EN 300 328, BIS, INMETRO, CU, RSS-247, EN 301 893
Power
Voltage Required
AC 120/230 V
Frequency Required
50/60 Hz
Power Factor Correction
Yes
Software / System Requirements
Software Included
Drivers & Utilities
Environmental Standards
Environmental Parameters
Min Operating Temperature
4.4 °C
Max Operating Temperature
41 °C
Humidity Range Operating
10 - 90% (non-condensing)
Dimensions & Weight
