General
Printer Type
Label printer - direct thermal / thermal transfer - monochrome
Printer
Print Speed
Up to 225 mm/sec - max speed - 203 dpi
Up to 100 mm/sec - 203 dpi
Built-in Devices
LCD touch screen
Connectivity Technology
Wireless
Interface
LAN, USB 2.0, USB 2.0 host, RS232, Wi-Fi(ac)
Max Resolution (B&W)
203 dpi
Language Simulation
Intermec Direct Protocol, Intermec Fingerprint, ZSim2, DPL, Extensible Mark-up Language (XML), PDF, C#, ZPL II, Intermec Printer Language (IPL)
Features
Ribbon end sensor, open head sensor, rewinder, Label Taken Sensor (LTS)
Barcodes
UPC, UCC/EAN-128, AIAG, OGMARS, Postnet, HIBCC, ISBT 128, GM1724
RAM
RAM Installed (Max)
256 MB
Technology / Form Factor
SDRAM
Flash Memory
Media Handling
Media Type
Gap, notch, black mark labels, continuous labels, ribbon, labels, tags
Max Media Size
Roll (17 cm)
Min Media Size (Custom)
76 mm
Max Media Size (Custom)
170 mm
Media Sizes
Roll (7.6 - 17 cm)
Max Printing Width
167.4 mm
Media Thickness Range
0.061 mm - 0.254 mm
Roll Maximum Outer Diameter
213 mm
Roll Core Diameter
38 mm, 76 mm
Media Feeders
1 x manual - 1 roll - Roll (17 cm)
RFID
Compliant Standards
ISO/IEC 18000-6C
Networking
Remote Management Protocol
TCP/IP, UDP, ICMP, SSH, SFTP, BOOTP, DHCP, HTTP, HTTPS, SNMP 1, SNMP 2c, SNMP 3
Security Protocols & Features
EAP-TTLS, FAST, LEAP, PEAP, WEP, WPA, WPA2
Expansion / Connectivity
Connections
1 x USB 2.0 host
1 x USB 2.0
1 x LAN
1 x RS-232
Miscellaneous
Compliant Standards
RoHS, EN 55032 Class B, FCC Class B certified
Power
Power Device
Power supply - internal
Voltage Required
AC 90-265 V
Frequency Required
50/60 Hz
Power Consumption Operational
400 Watt
Power Consumption Stand by
5 Watt
Software / System Requirements
Software Included
InterDriver Windows, CUPS driver for Linux, Honeywell Device Types, Honeywell Label Design and Print Package
Environmental Standards
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
Dimensions & Weight
