General
Printer Type
Label printer - thermal transfer - monochrome
Localisation
Rest of World
Printer
Print Speed
Up to 350 mm/sec - max speed - 203 dpi
Built-in Devices
LCD touch screen
Connectivity Technology
Wireless
Interface
USB 2.0, serial, Gigabit LAN, USB 2.0 host, Wi-Fi(ac), Bluetooth 5.0
Max Resolution (B&W)
203 dpi
Language Simulation
Intermec Printer Language (IPL), PDF, Intermec Fingerprint, Intermec Direct Protocol, Extensible Mark-up Language (XML), DPL, ZSim2
Features
Black Mark sensor, gap sensor, ribbon end sensor, paper low sensor, notch sensor
Barcodes
EAN/JAN, Code 93, Matrix 2 of 5, Industrial 2 of 5, Code 39, UCC/EAN-128, Code 49, ISBT 128, GS1 DataBar, QR code, MaxiCode, Aztec code, HIBCC, LOGMARS, MicroPDF417, Codabar, Code 128, Code 11, Code 16K, UPC, Interleaved 2 of 5, Postnet, PDF417, MSI-Plessey, Data Matrix, PLANET, Plessey, AIAG, Standard 2 of 5, Grid Matrix Code
RAM
RAM Installed (Max)
256 MB
Technology / Form Factor
SDRAM
Flash Memory
Media Handling
Media Type
Labels, linerless labels, fanfold paper, tag stock, tickets
Max Media Size
Roll (11.4 cm)
Min Media Size (Custom)
19 mm
Max Media Size (Custom)
114 mm
Media Sizes
Roll (1.9 - 11.4 cm)
Max Printing Length
4800 mm
Roll Maximum Outer Diameter
213 mm
Roll Core Diameter
76 mm, 38 mm
Media Feeders
1 x manual - 1 roll - Roll (11.4 cm)
Networking
Remote Management Protocol
SNMP 1, SNMP 3, SNMP 2c, HTTP
Security Protocols & Features
LEAP, WEP, TLS, WPA, WPA2, AES-CCMP, TTLS, PEAP, EAP-FAST
Expansion / Connectivity
Connections
1 x Gigabit LAN - RJ-45
1 x RS-232 - 9 pin D-Sub (DB-9)
1 x USB 2.0 - 4 pin USB Type B
2 x USB 2.0 host - 4 pin USB Type A
Miscellaneous
Included Accessories
Fixed media hanger
Cables Included
No power cord is included
Compliant Standards
FCC Class B certified, RoHS
Power
Power Device
Power adapter - external
Voltage Required
AC 100-240 V
Frequency Required
50/60 Hz
Power Consumption Operational
270 Watt
Power Consumption Stand by
9.6 Watt
Environmental Standards
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 80% (non-condensing)
Dimensions & Weight
