General
Printer Type
Label printer - direct thermal - monochrome
Printer
Print Speed
Up to 300 mm/sec - max speed - 300 dpi
Connectivity Technology
Wired
Interface
USB 2.0, LAN, serial, USB host
Max Resolution (B&W)
300 dpi
Language Simulation
ZPL II, Intermec Printer Language (IPL), DPL
Features
Rewinder, Label Taken Sensor (LTS), Black Mark sensor, gap sensor, notch sensor
Barcodes
UCC/EAN-128, Code 49, ISBT 128, QR code, MaxiCode, Aztec code, HIBCC, MicroPDF417, Code 16K, Postnet, PDF417, MSI-Plessey, PLANET, Plessey, AIAG, Grid Matrix Code, EAN-8, EAN-13, DataMatrix Inverse, RSS-14, DotCode, HIBC 39, HIBC 128, OGMARS, GM1724
RAM
RAM Installed (Max)
128 MB
Media Handling
Media Type
Labels, linerless labels, tags, fanfold labels
Max Media Size
Roll (11.4 cm)
Media Sizes
Roll (1.9 - 11.4 cm)
Media Thickness Range
0.06 mm - 0.26 mm
Roll Maximum Outer Diameter
213 mm
Roll Core Diameter
76 mm, 38 mm
Media Feeders
1 x manual - 1 roll - Roll (1.9 - 11.4 cm)
Networking
Remote Management Protocol
SNMP 1, SNMP 3, SNMP 2c, HTTP
Expansion / Connectivity
Connections
1 x USB 2.0 - 4 pin USB Type B ¦ 1 x LAN - RJ-45 ¦ 1 x USB host - 4 pin USB Type A ¦ 1 x RS-232
Miscellaneous
Compliant Standards
FCC Class A certified, NOM, SABS, SASO, CB, RoHS, EN 60950-1, S Mark, KC, EAC, RCM, EN 55022 Class A, EN 55032 Class A, CRS, NRCS
Power
Power Device
Power supply - internal
Voltage Required
AC 120/230 V
Frequency Required
50/60 Hz
Power Consumption Operational
300 Watt
Power Consumption Stand by
9 Watt
Software / System Requirements
Software Included
Drivers & Utilities
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 80% (non-condensing)
Dimensions & Weight
