General
Printer Type
Workgroup printer - dot-matrix - 24 pin - monochrome
Printer
Print Speed
Up to 487 char/sec - high speed - 10 cpi
Up to 529 char/sec - 12 cpi
Up to 366 char/sec - draft - 10 cpi
Up to 396 char/sec - 12 cpi
Up to 121 char/sec - LQ - 10 cpi
Up to 132 char/sec - 12 cpi
Connectivity Technology
Wired
Interface
USB 2.0, parallel, LAN
Max Resolution (B&W)
360 x 180 dpi
Max Resolution Class (B&W)
360 x 180 dpi
Language Simulation
EPSON ESC/P 2, IBM PPDS
Fonts Included
10 x bitmapped
4 x scalable
11 x barcode
Barcodes
NW-7, Code 128, Code 39, EAN-13, EAN-8, Industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, Postnet, UPC-A, UPC-E
RAM
RAM Installed (Max)
128 KB
Media Handling
Media Type
Continuous paper, labels, envelopes, cardboard
Max Sheets in Multi-Part Form
6
Expansion / Connectivity
Connections
1 x parallel - 36 PIN Centronics
1 x USB 2.0 - 4 pin USB Type B
1 x LAN - RJ-45
Miscellaneous
Consumables Included
1 x ribbon (black) - up to 10 million characters
Features
400 million strokes/wire printhead life
Power
Power Device
Power supply - internal
Power Consumption Operational
38 Watt
Power Consumption Stand by
3 Watt
Software / System Requirements
Software Included
EPSON Status Monitor
OS Required
Windows 10, Windows 11, Microsoft Windows 2000, Microsoft Windows 7, Windows 8, Microsoft Windows 98, Microsoft Windows Vista, Microsoft Windows XP, Microsoft Windows XP SP3 (32 bit) or later, Microsoft Windows Server 2003 SP2 or later
Manufacturer Warranty
Service & Support
Limited warranty - 1 year - carry-in
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 80%
Sound Emission (Operating)
59 dBA
Sound Emission (Quiet Mode)
54 dBA
Dimensions & Weight
Dimensions & Weight (Shipping)
Weight (Shipping)
8.674 kg
