General
Device Type
UPS - rack-mountable
Power Device
Input Voltage Range
AC 110 - 300 V / 160 - 300 V
Frequency Provided
50/60 Hz ± 3Hz
Frequency Required
40 - 70 Hz
Input Connectors
1 x power IEC 60320 C20
Power Output Connectors Details
6 x power IEC 60320 C13
Output Voltage
AC 220/230/240 V 50/60 Hz
Power Capacity
1800 Watt / 2000 VA
Surge Energy Rating
945 Joules
Circuit Protection
Circuit breaker
Battery
Networking
Remote Management Interface
RS-232, USB
Expansion / Connectivity
Interfaces
1 x management (USB) - 4 pin USB Type B
1 x management (RS-232) - 9 pin D-Sub (DB-9)
Miscellaneous
Included Accessories
Rack mounting rails, rack mounting brackets, tower feet
Cables Included
RS-232 cable
USB cable
RJ-45 cable
RJ-11 cable
Power cable (C13-C14)
Battery cable
Features
Status LCD display, LCD display, internal bypass, LED indicators, low battery alarm
Compliant Standards
CB, IEC 62040-2, RoHS, WEEE, KC, IP20, EAC, China RoHS, RCM, UN38.3, IEC 62040-1, TISI, REACH SvHC, EU RoHS, IEC 60730-1, UKCA, Green Premium, IEC 62619 1st Ed., IEC/EN 62040-2
Manufacturer Warranty
Service & Support
Limited warranty - replace or repair - 3 years
Limited warranty - replace or repair - batteries - 5 years
Environmental Parameters
Min Operating Temperature
-20 °C
Max Operating Temperature
50 °C
Humidity Range Operating
0 - 95% (non-condensing)
Dimensions & Weight
Dimensions & Weight (Shipping)
Compatibility Information
Designed For
APC Modbus Card SRVSMB001
