General
Device Type
UPS - external
Battery Enclosure Type
Internal
Power Device
Input Voltage Range
AC 98 - 140 V
Frequency Provided
50/60 Hz
Frequency Required
50/60 Hz
Input Connectors
1 x power NEMA 5-15P
Power Output Connectors Details
3 x power NEMA 5-15R (surge)
3 x power NEMA 5-15R (UPS and surge)
Output Voltage
AC 120 V 50/60 Hz
Power Capacity
300 Watt / 500 VA
Dataline Surge Protection
Phone line - RJ-11
Output Waveform
Stepped approximation to a sinewave
Compliant Standards
cUL, UL 1778, UL 1449
Battery
Features
Maintenance free, leak-proof
Expansion / Connectivity
Interfaces
1 x management
1 x management (USB)
Miscellaneous
Cables Included
USB cable - external
Power cable 1.83 m
Equipment Protection Value
100000 US Dollars
Compliant Standards
cUL, UL 1778, FCC Part 15 B, IC
Sustainability Information
Manufacturer Warranty
Service & Support
Limited warranty - replace or repair - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Min Storage Temperature
-15 °C
Max Storage Temperature
45 °C
Humidity Range Operating
0 - 95%
Humidity Range Storage
0 - 95%
Dimensions & Weight
Dimensions & Weight (Shipping)
Compatibility Information
Designed For
P/N: ACF600, AR106, AR106SH4, AR106SH6, AR109SH4, AR109SH6, AR112, AR112SH4, AR112SH6, AR8213, NBWL0356A, SCL500RM1UC, SCL500RM1UNC, SMTL1000RM2UC, SMTL750RM2UC
