ASUS ROG Loki SFX-L - Power supply (internal)

Productcode: 90YE00N1-B0NA00 | EAN/UPC: 4711081721901

€ 240,36 excl.btw

ASUS ROG Loki SFX-L - Power supply (internal) - ATX 3.0 / SFX-L - 80 PLUS Platinum - AC 100-240 V - 1000 Watt

ROG heatsinks
Axial-tech fan design
Dual ball fan bearings
0 dB technology
80 PLUS platinum certified
ATX 3.0 compatible
ARGB-illuminated fan and Aura Sync

Op voorraad: 3 stuk(s)

Levertijd:

Product:
ASUS ROG Loki SFX-L - Power supply (internal)

€ 290,84 incl. 21% btw € 240,36excl. 21% btw

Winkelwagen Offerte

Omschrijving

ASUS ROG Loki SFX-L - Power supply (internal) - ATX 3.0 / SFX-L - 80 PLUS Platinum - AC 100-240 V - 1000 Watt

Product features

ROG heatsinks
ROG heatsinks facilitate lower temperatures, longer component lifespan, and extended 0dB operation.
Axial-tech fan design
Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure. For ROG Loki PSUs, ASUS has scaled that design to 120 mm so it keeps things cool at low RPMs while producing less noise.
Dual ball fan bearings
The fan impeller spins on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design.
0 dB technology
To reduce noise output, the PWM-controlled fan shuts off entirely when the PSU load is 40% or below.
ATX 3.0 compatible
The power specification updates have landed. ATX 3.0 ushers in tighter voltage and current regulation guidelines for next-gen hardware - and ROG Loki steps ahead of the curve by being fully compliant. A 16-pin PCIe cable ripe for piping up to 600 W of power to PCIe Gen 5.0 graphics cards is bundled with the PSU, bringing large-scale capabilities to SFF rigs.
ARGB-illuminated fan and Aura Sync
The Loki's 120 mm fan features eight addressable LEDs ready to be customized with Aura Sync to create coordinated lighting patterns across your build.

Specificaties

General

Device Type

Power supply - internal

Specification Compliance

ATX 3.0 / SFX-L

PSU Form Factor

ATX

Power Device

Input Voltage

AC 100-240 V

Power Output Connectors Details

1 x power 24 pin ATX with detachable 4 pin section
1 x power 8 pin EPS12V with detachable 4 pin ATX12V section
1 x 16 pin PCI Express power
3 x 8 pin PCI Express power
6 x 15 pin Serial ATA power
4 x 4 PIN internal power

Output Voltage

+3.3, +5, ±12 V

Power Capacity

1000 Watt

Output Current

+3.3V - 20 A
+5V - 20 A
+12V - 83.3 A
-12V - 0.8 A
+5VSB - 2.5 A

Modular Cable Management

Yes

80 PLUS Certification

80 PLUS Platinum

Miscellaneous

Included Accessories

SFX to ATX bracket

Cables Included

AC input cable - external
Power 24 pin ATX modular cable 45 cm
2 x power 8 pin +12V with detachable 4 pin section modular cable 55 cm
16-pin 12VHPWR power cable 45 cm
16-pin 12VHPWR to 2x8 pin PCI Express power adapter 45 cm
2 x 3x Serial ATA modular cable 60 cm
ARGB sync cable 80 cm

Features

Overheat protection, over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, dual ball bearing cooling fan, fully modular, ASUS Aura Sync, ROG heatsink, Axial-tech fan design, ARGB fan

Compliant Standards

RoHS

Manufacturer Warranty

Service & Support

Limited warranty - 10 years
Limited warranty - RGB LEDs - 3 years

Dimensions & Weight

Width

12.5 cm

Depth

12.5 cm

Height

6.35 cm

Weight

1.83 kg

This data is supplied by 1WorldSync and matched through an automated process. Truedata is not responsible for errors in this data.
