This Gigabit Power over Ethernet (PoE+) injector supplies power and data connectivity to a Gigabit PoE-compliant device using standard Ethernet cable, at distances of up to 100 m (330 ft.).
The PoE midspan is a cost-effective alternative to upgrading your existing network switch to a PoE-capable model.
Convenience and cost savings
This versatile PoE injector lets you connect a PoE-powered device (PD) to a non-PoE network switch, so you can avoid the expense and aggravation of replacing your existing switch with a PoE-enabled model. It supplies up to 30 watts of power, so you can easily power and access a high-power PoE-compliant device, such as an IP camera or a wireless access point (WAP), using traditional copper (RJ45) Ethernet cable. The midspan injector makes it easy to extend data and power connectivity to your PoE+ device across long distances, even in a remote location where a typical power outlet isn’t available.
Easy to set up in mixed environments
You can integrate this compact injector discreetly into a variety of environments. It features a surface-mountable housing that’s perfect for installing on walls or under a desk, but it’s also palm-sized, for use on desktop surfaces.
Plus, with plug-and-play operation, you can enjoy fast and hassle-free setup without disrupting your workflow.
Intelligent power allocation
Not sure which class your PoE device is? The Gigabit PoE+ injector automatically detects the power requirements of your connected PoE PD, and delivers the appropriate level of power without damaging your device.
The POEINJ1G is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Netwerk
Ethernet interface type
Fast Ethernet, Gigabit Ethernet
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Bekabelingstechnologie
10Base-T, 100Base-TX, 1000Base-T
Power over Ethernet (PoE)
Ja
Netwerkstandaard
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ondersteundende kabel types
Cat5
Kenmerken
Kleur van het product
Zwart
Poorten & interfaces
Aantal Ethernet LAN (RJ-45)-poorten
2
Aansluiting voor netstroomadapter
Ja
Energie
Stroom via Ethernet (PoE)
48 V
Ingangsspanning
100 - 240 V
Certificaten
Certificering
RoHS, CE, FCC
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 45 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Temperatuur bij opslag
-40 - 85 °C
Gewicht en omvang
Afmetingen (B x D x H)
63 x 70 x 25 mm
Verpakking
Breedte verpakking
230 mm
Logistieke gegevens
Code geharmoniseerd systeem (HS)
85044095
