General
Device Type
VoIP phone adapter
Networking
Form Factor
Wall mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet
Network / Transport Protocol
ARP, DHCP, RTP, RTCP
Remote Management Protocol
HTTP, HTTPS, TFTP, SSH
Status Indicators
Power, phone
Features
Syslog support, DiffServ support, IPv6 support, full duplex mode, SNTP support, Quality of Service (QoS), reset button, LLDP support, DHCP client, Type of Service (ToS), Internet Control Message Protocol (ICMP), dual image support, AES encryption, Cisco Discovery Protocol, secure boot, VLAN Tagging
Compliant Standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.1ab (LLDP)
IP Telephony
VoIP Protocols
SIP, RTCP, RTP, SRTP
Voice Codecs
G.711, G.729a, G.729ab, G.711u, G.711a, T.38
Telephony Interfaces
2 phone (FXS)
IP Telephony Features
Echo cancellation, comfort noise generation (CNG), voice activity detection (VAD), call forwarding, Caller ID, adaptative jitter buffer, call waiting, call hold, call transfer, silence suppression
Expansion / Connectivity
Interfaces
1 x 100Base-TX - RJ-45
2 x FXS - RJ-11
Miscellaneous
Compliant Standards
FCC Part 15 B, EN 61000-4-2:2009, EN 61000-4-11:2004, EN 61000-3-3:2013, EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-8:2010, EN 61000-4-5:2014, EN 55024:2010+A1:2015, Directive 2014/35/EU, Directive 2014/30/EU, EN 61000-4.4:2012, UL 60950 Second Edition, CAN/CSA C22.2 No. 60950 Second Edition, ANSI C63.4-2014, AS/NZS 60950-1:2015, EN 61000-3-2:2014 Class A, EN 55032:2015 Class B, AS/NZS CISPR32:2015 Class B, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013
Power
Power Device
External power adapter
Voltage Required
AC 120/230 V / DC 5 V
Power Consumption Operational
5 Watt
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
