General
Bundled Services
2 Years Basic Onsite Service after Remote Diagnosis with Hardware-Only Support
Product Form Factor
All-in-one - with height-adjustable stand
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Processor / Chipset
CPU
Intel Core i5 (14th Gen) i5-14500T
Clock Speed
1.7 GHz (P-core) / 1.2 GHz (E-core)
Max Turbo Speed
4.8 GHz (P-core) / 3.4 GHz (E-core)
Power Efficiency
Energy Efficient
Cache Memory
RAM
Installed Size
16 GB / 64 GB (max)
Form Factor
SO-DIMM 262-pin
Slots
2 (Total) / 1 (empty)
Configuration Features
1 x 16 GB
Hard Drive
Interface Type
PCI Express 4.0 x4
Features
NVM Express (NVMe), Class 35
Optical Storage
Card Reader
Supported Flash Memory Cards
SD Memory Card, SDHC Memory Card, SDXC Memory Card
Monitor
Native Resolution
1920 x 1080 (Full HD)
V-Sync Rate at Max Res.
60 Hz
Horizontal Viewing Angle
+89 / -89
Vertical Viewing Angle
+89 / -89
Image Brightness
250 cd/m²
Image Contrast Ratio
1000:1
Monitor Features
Anti-glare, 3-sided bezeless, Dell ComfortView Plus
Graphics Controller
Graphics Processor
Intel UHD Graphics 770 Shared Video Memory (UMA)
Video Interfaces
DisplayPort
Audio Output
Compliant Standards
High Definition Audio
Speakers Included
2 x right / left channel
Camera
Resolution (MP)
2.07 Megapixel
Features
HDR (High Dynamic Range), retractable, 30 frames per second, RGB camera, 82 degrees
Input Device
Type
Mouse (on selected markets only), keyboard (on selected markets only)
Keyboard
Keyboard Name
Dell KM5221W Pro Wireless Keyboard and Mouse Combo
Audio Input
Networking
Interface (Bus) Type
M.2 2230
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 211
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E)
Features
Dual stream (2x2)
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax
Expansion / Connectivity
Slots
1 (total) / 0 (free) x M.2 Card - 2230/2280 ¦ 1 (total) / 0 (free) x M.2 Card - 2230
Interfaces
1 x LAN (Gigabit Ethernet) ¦ 1 x USB 3.2 Gen 2 (PowerShare) ¦ 1 x USB-C 3.2 Gen 2 ¦ 2 x USB 3.2 Gen 1 ¦ 2 x USB 2.0 (supports SmartPower On) ¦ 1 x audio line-out ¦ 1 x headphones/microphone ¦ 1 x DisplayPort 1.4a
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), chassis intrusion switch
Security Slot Type
Kensington security slot
Pricing Type
Build To Stock (BTS)
Power
Voltage Required
AC 100-240 V (50/60 Hz)
Operating System / Software
OS Provided
Windows 11 Pro
Software
Intel Rapid Storage Technology, Intel Connectivity Performance Suite, Dell Additional Softwares, No Microsoft Office License Included - 30 day Trial Offer Only
Sustainability Information
Carbon Footprint
335 kg carbon emissions
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
