General
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: German / region: Germany
Processor / Chipset
CPU
AMD Ryzen Embedded R2314
CPU Upgradability
Not upgradable
RAM
Installed Size
8 GB (installed) / 32 GB (max)
Effective Memory Speed
2667 MHz
Rated Memory Speed
3200 MHz
Form Factor
SO-DIMM 260-pin
Slots
2 (Total) / 0 (empty)
Configuration Features
2 x 4 GB
Hard Drive
Optical Storage
Monitor
Graphics Controller
Graphics Processor
AMD Radeon Graphics
Video Interfaces
DisplayPort
Audio Output
Input Device
Keyboard
Localization & Layout
German
Mouse
Networking
Ethernet Controller
Realtek RTL8111EPH-CG
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Expansion / Connectivity
Slots
1 (total) / 0 (free) x M.2 Card (for internal storage)
Interfaces
2 x USB 3.1 Gen 1 (2 front)
3 x USB-C 3.2 Gen 2 (1 front, 2 rear)
1 x audio line-out/line-in - mini-jack (1 front)
3 x DisplayPort 1.2 (3 rear)
2 x USB 3.2 Gen 1 (2 rear)
1 x LAN (Gigabit Ethernet) (1 rear)
1 x audio line-out/headphones (1 rear)
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
VESA Mounting Interface
100 x 100 mm, VESA
Compliant Standards
WEEE, EN 60601-1-2, ERP, CECP, RoHS2, SEPA, low halogen, EMV, HP GSE
Power
Power Device Name
HP Smart AC Adapter
Voltage Required
AC 100-240 V (50/60 Hz)
Operating System / Software
OS Provided
Windows 10 IoT Enterprise English / German
Software
HP Easy Tools, HP Device Manager, HP ThinUpdate, HP True Graphics, HP Easy Shell, Microsoft Edge, HP Write Manager, HP Cloud Endpoint Manager
Sustainability Information
TCO Certified
TCO Certified Desktops 9
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 1 year
Dimensions & Weight
Dimensions & Weight Details
3.5 cm - 20 cm - 20 cm - 1.174 kg - with stand
- 1.12 kg - without stand
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
