General
Platform Technology
AMD PRO
Bundled Services
3 Years Lenovo Premier Support
Built-in Devices
Front 4-digit diagnostic LED
Embedded Security
Discrete Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English, German, French, Dutch / region: Netherlands
Processor / Chipset
CPU
AMD Ryzen ThreadRipper PRO 7945WX
Cache Memory
Installed Size
L3 Cache - 64 MB
RAM
Installed Size
64 GB (installed) / 1 TB (max)
Technology
DDR5 SDRAM - ECC
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Slots
8 (Total) / 4 (empty)
Features
Registered, 8-channel memory architecture
Configuration Features
4 x 16 GB
Hard Drive
Interface Type
PCI Express 4.0 x4
Features
TCG Opal Encryption, NVM Express (NVMe), Performance
Storage Controller
Controller Interface Type
SATA 6Gb/s
RAID Level
RAID 0, RAID 1, RAID 5
Storage Controller (2nd)
Controller Interface Type
PCI Express (NVMe)
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Card Reader
Monitor
Audio Output
Compliant Standards
High Definition Audio
Input Device
Keyboard
Keyboard Name
Lenovo Traditional Keyboard
Localization & Layout
English
Mouse
Mouse Name
Lenovo Calliope Mouse
Networking
Ethernet Controller
Marvell AQtion AQC-113C, Realtek RTL8111EP
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet
Features
Wake on LAN (WoL)
Expansion / Connectivity
Bays
2 (total) / 2 (free) x internal 3.5"
Slots
4 (total) / 3 (free) x PCIe 5.0 x16 - full-length, full-height
2 (total) / 2 (free) x PCIe 5.0 x8 - full-length, full-height
1 (total) / 1 (free) x PCIe 4.0 x8
3 (total) / 2 (free) x M.2 Card
Interfaces
4 x USB 3.2 Gen 2 (1 front, 3 rear)
1 x USB-C 3.2 Gen 2x2
2 x USB 2.0
1 x LAN (10Gigabit Ethernet)
1 x LAN (25Gigabit Ethernet)
1 x audio line-in
1 x audio line-out
1 x headphones/microphone
1 x USB 3.2 Gen 2 (Always On)
2 x USB-C 3.2 Gen 2
Miscellaneous
Included Accessories
Lock kit (common key)
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), chassis intrusion switch
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, GREENGUARD, TCG Certified, TCO Certified 9.0
Manufacturer Selling Program
Lenovo TopSeller
Power
Voltage Required
AC 100-240 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Provided
Windows 11 Pro Dutch / English / French / German / Italian
Sustainability Information
EPEAT Compliant
EPEAT Gold
Manufacturer Warranty
Service & Support
Base warranty - 3 years - on-site
Extended warranty - 3 years - on-site - response time: next business day
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80%
