General
Device Type
All-in-One video bar
Kit Content
Poly TC8 controller, video bar
Voice Codecs
G.711, G.722, G.728, G.729a, G.722.1, G.722.1c, G.719
Video Codecs
H.264 AVC, H.264 High Profile, H.265, H.239
Dimensions & Weight Details
Video bar - Width 76.2 cm Depth 10.2 cm Height 10.2 cm Weight 2.54 kg
Touch screen - Width 20.5 cm Depth 7.9 cm Height 12.3 cm Weight 812 g
Built-in Devices
Camera, stereo speakers, 3 MEMS microphones, 2 2nd order microphones
Display
Native Resolution
1280 x 800
Monitor Features
LED-backlit, capacitive touch screen, 150° horizontal and vertical viewing angle
Video Input
Type
Digital camera - integrated
Digital Video Capture Resolution
3840 x 2160, 1920 x 1080, 1680 x 1050, 1600 x 1200, 1280 x 1024, 1280 x 768, 1280 x 720, 1024 x 768, 800 x 600
Video Modes
720/60p, 1080/60p, 1080/30p, 720/30p, 4K
Features
Poly NoiseBlockAI technology, Poly Acoustic Fence technology, 121° field of view (diagonal), 110° field of view (horizontal), UHD 2160p (4K) capture resolution, automatic group framing, automatic people framing
Video Output
Max External Resolution
3840 x 2160
Supported Display Graphics
UHD (3840 x 2160), WUXGA (1920 x 1200), HDTV (1920x1080), WSXGA+ (1680 x 1050), SXGA+ (1400x1050), SXGA (1280x1024), HD (1280 x 720), XGA (1024x768)
Digital Video Standard
High-Definition Multimedia Interface (HDMI)
Audio Input
Type
Three microphones - integrated
Audio Output
Networking
Connectivity Technology
Wireless, wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0
Network / Transport Protocol
IPv4, IPv6
Features
Automatic Media-Dependent Interface Crossover (MDIX), Polycom Lost Packet Recovery (LPR) technology, dynamic bandwidth allocation, NT LAN Manager (NTLM), digest authentication, IPv4 support, IPv6 support, MIMO technology
Performance
Frame rate: 5 - 60 fps
Expansion / Connectivity
Interfaces
1 x audio / video - HDMI input - 19 pin HDMI Type A
2 x audio / video - HDMI output - 19 pin HDMI Type A
2 x SuperSpeed USB 3.0 - 9 pin USB Type A
1 x USB-C - 24 pin USB-C
1 x audio - line-In - mini-phone 3.5 mm
1 x audio - line-out - mini-phone 3.5 mm
2 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45
Miscellaneous
Cables Included
1 x CAT5E network cable
1 x HDMI cable
1 x power cable
Included Accessories
Wall mount kit
Software Certification
Zoom Certified, Certified for Microsoft Teams, Google Meet Certified
Power
Power Device
Power adapter - external
Voltage Required
AC 120/230 V (50/60 Hz)
Software / System Requirements
Software Included
Poly Lens management software
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
15 - 80%
