General
Host Connectivity
Gigabit Ethernet
Enclosure Type
Rack-mountable - 2U
Total Storage Capacity
32 TB
Max Supported Capacity
320 TB
Installed Devices / Modules Qty
8 (installed) / 12 (max)
Processor / Memory
Processors Installed
1 x Intel Xeon Bronze 3408U 1.8 GHz
Features
Registered, single rank, HPE SmartMemory
Storage Controller
Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
HPE MR416i-o Gen11 SPDM
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, 1ADM, 10ADM
Hard Drive
Type
HDD - hot-swap - 3.5" LFF
Networking
Data Link Protocol
10Mb LAN, 100Mb LAN, 1GbE
Network Services Compatibility
DNS, DHCP, Microsoft CIFS, Network File System (NFS), FTP, FTPS, Server Message Block (SMB), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV)
Features
Trusted Platform Module (TPM)
Expansion / Connectivity
Expansion Bays
12 (total) / 4 (free) x hot-swap - 3.5" LFF
Expansion Slots
2 (total) / 0 (free) x FlexibleLOM ¦ 1 (total) / 1 (free) x PCI Express 4.0 x16 (half-length, full-height) ¦ 1 (total) / 1 (free) x PCI Express 4.0 x8 (half-length, full-height) ¦ 1 (total) / 1 (free) x PCI Express x8 (power only) (half-length, full-height)
Interfaces
4 x Ethernet 1000Base-T (rear) ¦ 1 x HPE iLO (service) - Type A
Miscellaneous
Cables Included
2 x power cable (C13-C14) - 1.83 m
Compliant Standards
WEEE 2002/95/EC
Included Accessories
6 x hot-plug high-performance redundant fan
Power
Power Device
Internal power supply - hot-plug
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 200-240 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Software / System Requirements
Storage Operating System
Microsoft Windows Storage Server IoT 2022 Standard
Software Included
HPE iLO Advanced Premium Security Edition with 1 Year Support, HPE StoreEasy Management Console
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
