General
Device Type
Switch - 16 ports - smart
Enclosure Type
Rack-mountable
Ports
4 x 10/100/1000 (PoE++) + 10 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP (PoE+)
Performance
Non-blocking bandwidth: 16 Gbps
Switching capacity: 32 Gbps
MAC Address Table Size
8K entries
Remote Management Protocol
HTTP, CLI
Features
Flow control, auto-negotiation, trunking, VLAN support, WOL, IGMP snooping, port mirroring, ACL support, LACP support, LLDP support, DHCP client, Energy Efficient Ethernet, loop prevention, SDN, schedule PoE, DNS client, port-based VLAN, port-based QoS, SNTP client, DSCP based QoS
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt
Processor
1 x Intel Celeron J4115: 1.8 GHz
RAM
4 GB (installed) / 8 GB (max) - SO-DIMM 260-pin - DDR4 SDRAM
Built-in Devices
Status LCD, 2 x 2.5" SATA 6Gb/s drive bays
Status Indicators
Link/activity, speed
Expansion / Connectivity
Expansion Slots
2 (total) / 2 (free) x PCI Express 2.0
Power
Power Device
Internal power supply
Voltage Required
AC AC 100-240 V (50/60 Hz)
Power Consumption Operational
100 Watt
Miscellaneous
Rack Mounting Kit
Included
Compliant Standards
VCCI, BSMI, FCC, RCM
Dimensions & Weight
Dimensions & Weight (Shipping)
Manufacturer Warranty
Service & Support
Limited warranty - 2 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
