General
Device Type
Solid state / hard drive array
Enclosure Type
Rack-mountable - 2U
Chassis
Installed Devices / Modules Qty
2
Supported Devices / Modules Qty
24
Storage
Total Array Capacity
1.6 TB
Max Supported Capacity
960 TB
Processor
Storage Controller
Data Transfer Rate
600 MBps
Cache / Buffer Size (Max)
8 GB
RAID Level
RAID 1, RAID 5, RAID 6, RAID 10
Storage Controller (2nd)
Hard Drive
Expansion / Connectivity
Expansion Bays
24 (total) / 22 (free) - 2.5" SFF
Interfaces
4 x Ethernet 10Gb (iSCSI) / 16Gb Fibre Channel ¦ 2 x mini-USB 2.0 (management) ¦ 2 x Ethernet 1000Base-T (management) - RJ-45 ¦ 2 x SAS
System Requirements
OS Required
HP-UX, SuSe Linux, Red Hat Enterprise Linux, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016
Miscellaneous
Features
Systems Insight Manager (SIM)
Software Included
HPE Advanced Data Services Suite
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN55022, GS, EN 61000-3-3, EN55024, CCC, FCC Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A, KN24, KN22 Class A, CNS 13438 Class A, ICES-003:2004 Class A
Environmental Standards
Power
Power Device
2 x internal power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 120/230 V - 50/60 Hz
Power Consumption Operational
390 Watt
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - parts - 3 years
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
