General
Device Type
Solid state drive - internal
NAND Flash Memory Type
20nm multi-level cell (MLC)
Interface
PCI Express 3.0 x4 (NVMe)
Features
Read Unrecoverable Bit Error Rate (UBER) 10e-16, Temperature Monitoring and Logging, Enhanced Power Loss Data Protection, half-height half-length form-factor, S.M.A.R.T.
Performance
Internal Data Rate
2500 MBps (read) / 1200 MBps (write)
4KB Random Read
460000 IOPS
4KB Random Write
290000 IOPS
Reliability
Non-Recoverable Errors
1 per 10^16
Expansion & Connectivity
Interfaces
1 x PCI Express 3.0 x4 (NVMe)
Power
Power Consumption
22 Watt (write) ¦ 10 Watt (read) ¦ 4 Watt (idle)
Software & System Requirements
OS Required
Microsoft Windows 7 / Windows 8 / Windows 8.1 (64 bits)
Miscellaneous
Compliant Standards
UL, VCCI, C-Tick, BSMI, WHQL, RoHS, KCC, WEEE, EN 60950-1 Second Edition, CEM, EN 61000-4-2:95, EN 61000-4-3:96, EN 61000-4-4:95, EN 61000-4-5:95, EN 61000-4-6:97, EN 61000-4-11:94, ENV 50204:95, ICES-003 issue 4, EN 55024:2010, EN 55022:2010, WHCK
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
55 °C
Humidity Range Operating
5 - 95%
Shock Tolerance (operating)
50 g
Shock Tolerance (non-operating)
50 g
Vibration Tolerance (operating)
2.17 g @ 5-700 Hz
Vibration Tolerance (non-operating)
3.13 g @ 5-800 Hz
