General
Device Type
Switch - 24 ports - L3 - Managed - stackable
Enclosure Type
Rack-mountable 1U
Performance
Switching capacity: 208 Gbps ¦ Stacking bandwidth: 480 Gbps ¦ Forwarding rate: 154.76 Mpps
Capacity
QoS queues: 8 ¦ Member ports per aggregated link: up to 8 ¦ VLANs with trunking: 4094
MAC Address Table Size
32000 entries
Routing Protocol
IGMP, VRRP, OSPFv2, static IP routing, MSTP, RSTP, STP
Remote Management Protocol
SNMP, DHCP, IPv4, IPv6, Syslog
Authentication Method
RADIUS
Features
VLAN support, port mirroring, Broadcast Storm Control, firmware upgradable, Per-VLAN Spanning Tree (PVST), DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), STP Root Guard, Uni-Directional Link Detection (UDLD), DHCP relay, Cisco StackPower technology, hot swappable 3 fans, network diagnostics, Role-Based Access Control (RBAC), push notification, STP BPDU Guard, STP loop guard, Zero-touch provisioning (ZTP), DSCP to CoS Mutation, Protocol Independent Multicast (PIM), MAC Access Bypass (MAB), VLAN trunking, Cisco Discovery Protocol (CDP), Rapid PVST (RPVST), sticky MAC, adaptive policy, usage statistics
Compliant Standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP)
Expansion / Connectivity
Interfaces
24 x 1000Base-T RJ-45 ¦ 2 x network stack device ¦ 1 x management ¦ 1 x USB Type A ¦ 1 x USB Type B console
Expansion Slots
1 (total) / 1 (free) x Expansion Slot
Power
Power Device
Internal power supply - hot-plug
Voltage Required
AC 100-240 V (50 - 60 Hz)
80 PLUS Certification
80 PLUS Platinum
Miscellaneous
Rack Mounting Kit
Included
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, ICES-003 Class A, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, CNS 13438, EN 300 386 V1.6.1, EN 55022 Class A, KN32, KN35, EN 55032, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, TCVN 7317, AN/NZS 60950.1, V-2/2015.04, V-3/2015.04, FCC CFR 47 Part 15 Class A, VCCI-CISPR 32 Class A
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - advanced replacement - lifetime - response time: next business day
Environmental Parameters
Min Operating Temperature
-5 °C
Max Operating Temperature
45 °C
Humidity Range Operating
5 - 90%
Min Storage Temperature
-20 °C
Max Storage Temperature
70 °C
