General
Networking
Form Factor
Rack-mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol
L2TP, IPSec, SMTP, POP3
Routing Protocol
OSPF, RIP-1, RIP-2, BGP
Remote Management Protocol
SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS
Performance
Firewall throughput: 2.3 Gbps
VPN throughput: 810 Mbps
Intrusion detection and prevention throughput: 1.15 Gbps
Antivirus throughput: 800 Mbps
Unified Threat Management (UTM) throughput: 800 Mbps
Capacity
Concurrent TCP sessions: 1000000
Concurrent IPSec VPN tunnels: 300
Concurrent SSL VPN users: 150
Virtual interfaces (VLANs): 64
Concurrent logins: 200
Manageable access points: 8
Status Indicators
Power, system
Features
Firewall protection, routing, DHCP support, NAT support, VPN support, PAT support, SNAT support, load balancing, LDAP support, VLAN support, Syslog support, DoS attack prevention, content filtering, ALG support, dynamic DNS server, IPv6 support, antivirus analysis, High Availability, firmware upgradable, DDos attack prevention, tunnelling, IPSec Virtual Private Network (VPN), Wi-Fi Multimedia (WMM) support, anti-spam protection, Access Control List (ACL) support, Quality of Service (QoS), Dead Peer Detection (DPD), IPSec NAT-Traversal (NAT-T), SSH support, VPN failover, DHCP server, IPv4 support, 3G USB Dongle Support, DHCP relay, IP-MAC binding, CAPWAP support, DHCP client, dual firmware images, static routing, tagged VLAN, Captive Portal, Generic Routing Encapsulation (GRE), Intrusion Detection and Prevention (IDP), VPN concentrator, VPN load-balancing, VPN auto-reconnection, Single Sign-On (SSO) support
Encryption Algorithm
DES, Triple DES, MD5, IKE, SSL, SHA-1, PKI, 256-bit AES, IKEv2, 512-bit SHA-2
Authentication Method
Secure Shell (SSH), RADIUS, X.509 certificates, LDAP, Active Directory, Extensible Authentication Protocol (EAP), XAUTH authentication
Compliant Standards
IEEE 802.1Q, X.509
Expansion / Connectivity
Interfaces
7 x 1000Base-T - RJ-45
1 x - SFP (mini-GBIC)
2 x USB - Type A
1 x console - DB-9
Miscellaneous
Included Accessories
Rack mount kit
Compliant Standards
CSA, ICSA IPSec certified, ICSA Firewall certified, VCCI Class B ITE, ICSA Antivirus, CSA 22.2 No. 60950, C-Tick Class B, FCC Part 15 B, EMC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE
Power
Power Device
External power adapter
Power Consumption Operational
24.1 Watt
Dimensions & Weight (Shipping)
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
