General
Networking
Connectivity Technology
Wired
Data Transfer Rate
1300 Mbps
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol
IPSec, L2TP, DNS, PPPoE, DDNS
Routing Protocol
Static IP routing, policy-based routing (PBR), RIP-1, RIP-2, OSPF
Remote Management Protocol
HTTP, HTTPS, SNMP 1, SNMP 2c, SNMP 3
Frequency Band
2.4 GHz, 5 GHz
Performance
Firewall throughput: 350 Mbps
VPN throughput: 90 Mbps
Capacity
User licences: unlimited
Concurrent IPSec VPN tunnels: 10
Concurrent sessions: 20000
Concurrent SSL VPN users: 1
SSL VPN users: 5
Maximum number of configured SSIDs: 8
Features
Bandwidth control, manageable, IPv6 support, VPN support, routing, Transparency, Stateful Packet Inspection (SPI), ALG support, DoS attack prevention, DDos attack prevention, stackable, tunnelling, VLAN support, IPSec Virtual Private Network (VPN), IPSec NAT-Traversal (NAT-T), Dead Peer Detection (DPD), VPN auto-reconnection, High Availability, load balancing, failover protection, Generic Routing Encapsulation (GRE), PAT support, tagged VLAN, SNAT support, DHCP client, DHCP server, DHCP relay, Single Sign-On (SSO) support, Syslog support, E-mail alert, firmware upgradable, dual firmware images, ZyXEL One Network (ZON), SmartConnect Technology, Quality of Service (QoS), Wi-Fi Multimedia (WMM) support, CAPWAP support, Multiple SSID support, Captive Portal, Dynamic Channel Control
Encryption Algorithm
SSL, SHA-1, MD5, 256-bit AES, DES, Triple DES, 512-bit SHA-2, IKEv2, IKE, PKI
Authentication Method
X.509 certificates, LDAP, RADIUS, XAUTH authentication, Radio Service Set ID (SSID)
Compliant Standards
X.509, IEEE 802.1Q, IEEE 802.11ac, IEEE 802.11n, IEEE 802.1x
IP Telephony
Aerial
Antenna
External detachable
Expansion / Connectivity
Interfaces
4 x 1000Base-T - RJ-45 (LAN / DMZ)
1 x 1000Base-T - RJ-45 (WAN)
1 x USB - Type A
1 x - SFP (mini-GBIC)
1 x console - RJ-45
Miscellaneous
Cables Included
1 x console cable
Compliant Standards
FCC Part 15 B, IC, EMC Class B, RCM, BSMI, UL, ICSA Firewall certified
Power
Power Device
External power adapter
Power Consumption Operational
12 Watt
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
